Victory ROSE - Electrical Connection Details; Connecting to a Power Source

L1-N230VAC
L2-N230VAC
L3-N230VAC
5
5x4mm
2
N
L1
L2
L3
PE
5
5x4mm
2
PEL3L2L1N
Connectiontoapowersource:
FeedercablemustbeconnectedtoapermanentinstallationofIP X5securitylevel.
Fittingofplugisnotallowed.Permanentinstallationlocatedinthewallmaybeconnected
throughthejunctionbox.IP X5junctionboxshallbelocatedbeyondthebodyofthebathtub
andabove20cmfromthefloor.Connectiontoapowersourceshallbeconductedthrougha
cableof5x4mm through25A powerexcessswitchbystandardinstalledinthebathtub.
Remark!Bathtubisequippedwithfeedercablesofthefollowingcolors:
PhaseconductorL:blackorbrown
NeutralconductorN:blue
Protectionconductor:yellow-green
2
!
!
!
Wayofconnectiontoapowersource
Powerexcessswitch
B25/phaseln=0,03A
3PHASES:
