TV Overview
4. MENU - Press the MENU button to display. Press VOL+ to select from the 6 menu options available.
Press the CH+ / CH- buttons to select a feature from the selected menu then press the VOL+/VOL- buttons
to adjust the volume settings.
2. )+ HC -( lennahC eht sserP - CH
-
+ HC /
buttons to select a channel in the TV mode.
3. Volume (+VOL-) - Press the VOL+ / VOL- buttons to adjust the volume up or down.
Front & Rear Panel
1. STANDBY - Press the STANDBY button to turn the TV ON/ OFF (power). The screen image will
appear within a few seconds, and the Green LED will turn on.
IR Receiver
A soft green light illuminates when the
television power is on.
55V40UHD-11
5. INPUT - After connecting your DVD, cable box, etc. select the appropriate input source to view. Press the
INPUT button to display the input options. Press the CH+ / CH- buttons to highlight the input source and
press the VOL+ button to select.
Source Select
TV
AV
Component
HDMI1
HDMI2
HDMI3
HDMI4
Media
