55V800R -7
Place the TV face down
on a soft cloth or cushion.
Position base as shown.
Insert 5 screws (provided)
through the holes in the bottom
of the base into the post holes
and tighten securely.
Do not over-tighten.
Installing the Base
Removing the Base
To use the TV with a wall
mount first remove the base by
removing the 7 screws shown
to the left.
