INSTALL SHEET
OMV OUTDOOR MOTION VIEWER
Optional lenses
The OMV MotionViewer is provided with 3 optional lenses. With these lenses the detection can be adapted to
the site environment.
Long range beam lens
Pet-immune lens
(horizontal curtain)
Max detection distance :
CURTAIN LENS
Tilt angle
OMV 611 Tilt angle
5° 10° 15° 20° 30°
10°
Mounting height
2.5 m 12 m* 11 m 8 m 6,5 m
2.75 m 12 m* 12 m 9 m 7 m 5 m
3 m 12 m* 12 m* 9,5 m 7, 5 m 5,5 m
3.25 m 12 m* 10 m 8 m 5,5 m
3.5 m 12 m* 11 m 8,5 m 6 m
29 ft
Curtain lens (vertical)
1m
1m80
29 max for OMV611 at 3.5m height and 10° tilt angle
29 max for OMV611 at 3.5m height and 10° tilt angle
