Rev AA Optional Accessories A-5
Videojet 1710 Operator Manual
Static Printer Stand
Printhead Stand
(25.12 inches)
670 mm
670 mm
(26.37 inches)
(26.37 inches)
638.16 mm
Figure A-4: Static Printer Stand
(70 inches)
(44.1 inches)
(14.2 inches)
(10.2 inches)
260 mm
360 mm
1548 mm
1120 mm
Figure A-5: Printhead Stand
