3-12 Connector Panel Rev AA
Videojet 1710 Operator Manual
Connector Panel
The connector panel is on the left side of the printer (item 5, Figure 3-1 on
page 3-1). The panel contains the connectors shown in Figure 3-12.
The standard printer is the IP55 printer, which has PCB 5 fitted. The optional
printer is the IP65 printer, which has PCB 1 and PCB 2 (
Figure 3-13 on
page 3-14).
Note: The number of connectors provided depends on the model you select.
2
1
1. Umbilical
2. Printhead
Figure 3-11: Printhead and Umbilical
