14
VIDEOMAN
Doorstation
FUTURO-CZ4 (surface mount) / FUTURO-CP4 ( flush mount )
Power
Operation Power (B+)
12VDC from Monitor
Button Back Light Power (12V)
12VDC from Monitor
Camera
1/3" Colour CCD sensor, Viewing angle 110 °
Door Release (D/O)
Voltage free Dry Contact, Normally Open
Night Vision LED's
6 White LED's
Operating Temperature
0 °C ~ 40 °C
Operating Humidity
Less than 90%
Dimensions (W/H/D) mm
FUTURO-CZ4
99 x 148 x 28
FUTURO-CP4
128 x 182 x 4 (Metal Plate)
98 x 155 x 55 (Embedding Box)
Power supply for Monitors
FUTURO-4PS1A
Input
100 - 240VAC, 50 ~ 60Hz, 0.45Amp
Output
13.0VDC, 1.2Amp
Operating Temperature
0 °C~ 40 °C
Operating Humidity
Less than 90%
