Technical Specification 13
FUTURO
6 Technical Specification
Monitor
FUTURO-SD4B ( no photo recording function )
Power
FUTURO-PS4(Switching Mode Power Adaptor)
Input: 240VAC, 450mA, 50Hz Output: 13VDC, 1.2A
Display
7” Colour TFT-LCD
Transmitted Method
Doorstation : 5 wires (Polarity conscious)
Sub monitor: 4 wires (Polarity conscious)
Call Tone
16 different Poly-Phonic Melodies
Screen off timer
Standby : 40 sec, While talking: 120 sec
Recommended cable
requirements between
Monitor & Doorstation
< 50M
4 of 14/020 Shielded cable
(Connect shield to GND)
AND
RG-59/U coaxial cable for Video signal
(Connect shield to GND)
< 100M
4 of 24/020 shielded cable
(Connect shield to GND)
AND
RG-59/U coaxial cable for Video signal
(Connect shield to GND)
Operating Temperature
0 °C ~ 40 °C
Operating Humidity
Less than 90%
Dimensions (W/H/D)
235mm x 128mm x 25mm
Weight
860g
FUTURO-SD4 (photo recording function) only
Internal Photo Memory
Up to 80 photos triggered by CALL button
External Video Memory
Optional FUTURO-SD-Card triggered by motion detection
Status LED description
LED Status
ON
BLINK
Blue
POWER
Baby Monitoring (one way audio)
Red
Melody Mute
Paging ( two way audio)
Green
New Photo recorded
Recording status by motion
