Monitor Description 3
FUTURO
1 Monitor Description
FUTURO-SD4 : with Photo Recording Function
FUTURO-SD4B : without Photo Recording Function
1 2
EOL
1
7" TFT LCD SCREEN
12
►FORWARD
2
POWER & BABY MONITORING LED (WHITE)
13
■ SETUP / MEMORY MODE
3
MELODY MUTE LED (RED)
14
X DELETE PHOTO
4
PHOTO RECORDING LED (GREEN)
15
BRIGHTNESS
5
TALK
/ Melody Volume / Baby Monitoring Activate
16
CONTRAST
6
MONITORING
/ Setup / Melody Select
17
SPEAKER VOLUME
7
DOOR OPEN
/ Melody Mute / Save setup
18
SPEAKER
8
INTERPHONE
/Paging
19
DOORSTATION TERMINAL
9
FUTURO-SD-CARD SLOT
20
SUB MONITOR TERMINAL
10
MICROPHONE
21
POWER TERMINAL
11
◄ BACKWARD
22
EOL(End of Line) Termination Switch
