Wires to the water tank and battery must be extended. See detail below.
TO THE EVAPORATOR UNIT
DUAL
RESTRICTION VALVE
QUICK CONNECTION
TO THE WATER
PUMP
TO THE WATER PUMP
AND LEVEL SENSOR
TO THE BATTERY
YELLOW
YELLOW-R
RED
BLACK
RED
BLACK
