9. Technical data
DC-operation 0 to 24 V max
Digital systems: DCC, MM
Feedback protocol: RailCom
Operating voltage: 12 – 24 V digital
Standby current: ca. 20 mA
Total operating current (continous): 800 mA
Motor current: 500mA, 800mA (peak)
Function outputs: 2 (each output can handle up
to 300mA, however, the total current of all func-
tion outputs may not exceed 300mA), short-cir-
cuit proof
Thermal shut down
Degree of protection: IP 00
Ambient temperature (operating): 0 - +60 °C
Permitted relative humidity: max. 85 %
Dimensions: ca. 11,5 x 9,5 x 2,6 mm
9. Technische Daten
Gleichstrombetrieb0bis24Vmax
Digitalsysteme:DCC,MM
Rückmeldeprotokoll:RailCom
Betriebsspannung:12–24VDigitalspannung
Stromaufnahme(ohneLast):ca.20mA
Gesamtstrom dauerhaft: 800 mA
Motorstrom: 500 mA, kurzzeitig 800 mA
Funktionsausgänge:2(jederAusgangkanneinen
maximalenStromvon300mAliefern,dieSumme
darfaber300mAebenfallsnichtübersteigen),
kurzschlussfest
Übertemperaturgesichert
Schutzart:IP00
Umgebungstemperatur(Betrieb):0-+60°C
ZulässigerelativeLuftfeuchtigkeit:max.85%
Abmessungen: ca. 11,5 x 9,5 x 2,6 mm
85844
Stand 04/sw
12/2018
Ho/Za/Ir
Änderungenvorbehalten.KeineHaftungfürDruck-
fehlerundIrrtümer.
DieaktuelleVersionderAnleitungfindenSieauf
derViessmannHomepageunterderArtikelnummer.
Subject to change without prior notice. No liability for
mistakes and printing errors.
You will find the latest version of the manual on the
Viessmann website using the item-No.
Entsorgen Sie dieses Produkt nicht über
den(unsortierten)Hausmüll,sondernfüh-
renSieesderWiederverwertungzu.
Do not dispose of this product through (unsorted)
domestic waste, supply it to recycling instead.
