5
5696 674 - 03
Vitocell 300-H, EHA Series Technical Data
42 and 53 USG (160 and 200 L)
Technical Data
Legend
AQ Aquastat Well
BWR Boiler Water Return
BWS Boiler Water Supply
DCW Domestic Cold Water
DHW Domestic Hot Water
IO Inspection and Clean-out Opening
TPV Temperature and Pressure Relief Valve
RT Recirculation tapping
92 and 119 USG (350 and 450L)
Legend
AQ Aquastat Well
BWR Boiler Water Return
BWS Boiler Water Supply
DCW Domestic Cold Water
DHW Domestic Hot Water
IO Inspection and Clean-out Opening
TPV Temperature and Pressure Relief Valve
Dimensions
Storage capacity USG (L) 42 (160) 53 (200)
a in. (mm) 34 (866)
40b (1030)
Dimensions
Storage capacity USG (L) 92 (350) 119 (450)
a in. (mm) 55 (1397)
57b (1461)
b in. (mm)
2a (57) 2c (72)
c in. (mm)
5b (139) 5b (138)
d in. (mm)
6c (170)
8 (203)
e in. (mm)
5a (133) 5a (137)
f in. (mm) 3 (78) 3 (78)
g in. (mm)
14b (368)
16 (409)
h in. (mm) 23 (586) 25 (636)
k in. (mm)
7b (193)
9 (226)
l in. (mm)
23b (594) 26c (677)
