Page 21 GB 9 - 9.1 Right reserved to make technical changes!
9. Drawings
9.1 Schematics of the refrigeration circulation
1 Compressor
2 Pressure lead
3 Hot gas U-pipe in defrost water pan
4 Condenser
5 High pressure switch
6 Heat exchanger
7 Drier
8 Thermal expansion valve
9 Evaporator
10 Suction pipe
11 Coldroom
1
2
3
4
5
6
7
8
9
10
11
