Setting the air flow rates for Vitovent 200-C
1. Service menu:
Press OK +
å
simultaneously and hold for
approx. 4 s.
2. "Parameter level 1"
3. Set the air flow rates using the following parame-
ters:
■
"7D0A Flow rate, reduced ventilation"
■
"7D0B Flow rate, nominal ventilation"
■
"7D0C Flow rate, intensive ventilation"
Note
For Vitovent 200-C, the air flow rate for "Back-
ground vent." is set at the factory to 50 m
3
/h and
cannot be adjusted.
Setting the air flow rates for Vitovent 300-C/300-W
1. Service menu:
Press OK +
å
simultaneously and hold for
approx. 4 s.
2. "Parameter level 1"
3. Set the air flow rates using the following parame-
ters:
■
"C109 Background ventilation"
■
"C10A Reduced ventilation"
■
"C10B Standard ventilation"
■
"C10C Intensive ventilation"
Adjusting the air flow rates
"Air distribution systems" installation and service
instructions
Balancing the supply air/extract air flow rates
Note
Balancing is only required if the total of the actual air
flow rates of all supply air apertures deviates by more
than 10 % from that of all extract air apertures.
Vitovent 200-C
To balance out the air flow rate differentials, the control
voltages of the supply and/or exhaust air fan can be
permanently increased or reduced.
1. Service menu:
Press OK +
å
simultaneously and hold for
approx. 4 s.
2. "Parameter level 1"
3. Set the control voltages:
■
"Control voltage matching, supply air fan
7D71"
■
"Control voltage matching, exhaust air fan
7D72"
Vitovent 300-C
1. Service menu:
Press OK +
å
simultaneously and hold for
approx. 4 s.
2. "Parameter level 1"
3. Set "Imbalance permitted C1A2" to "1".
4. An increase or decrease in the supply air flow rate
in comparison to the extract air flow rate can be set
with "Specified imbalance C1A3".
