22
Vitovent
200-C 300-C 300-W
X — —
Set extract air temperature for ventilation mode
■
At extract air temperatures < "Set extract air tem-
perature 7D08" minus 1 K, the bypass can be ena-
bled for passive heating. The outdoor air/extract air
is not routed via the heat exchanger.
■
At extract air temperatures > "Set extract air tem-
perature 7D08" plus 1 K, the bypass can be ena-
bled for passive cooling. The outdoor air/extract air
is not routed via the heat exchanger.
Note
Further conditions must be met in order for passive
heating and passive cooling to be switched on: See
"Min. supply air temperature for bypass 7D0F" and
chapters "Passive heating", "Passive cooling" in the
"Function description".
Setting 1 ≙ 0.1 °C
7D0A Flow rate, reduced ventilation !
Vitovent
200-C 300-C 300-W
X — —
Set air flow rate for the "Reduced" operating status in
the ventilation time program (ventilation level 2).
Setting subject to the building and engineering.
Standard setting values:
■
Centrally between 70 m
3
/h and "Flow rate, nominal
ventilation 7D0B"
or
■
Approx. 30 % lower than "Flow rate, nominal venti-
lation 7D0B"
Setting in m
3
/h
7D0B Flow rate nominal ventilation !
Vitovent
200-C 300-C 300-W
X — —
Set air flow rate for the "Standard" operating status in
the ventilation time program.
Set the design air flow rate from the engineering
parameters here.
Setting in m
3
/h
7D0C Flow rate intensive ventilation !
Vitovent
200-C 300-C 300-W
X — —
Set air flow rate for the "Intensive" operating status in
the ventilation time program or "Intensive mode".
Setting subject to the building and engineering.
Standard setting values:
■
Centrally between "Flow rate, nominal ventilation
7D0B" and 200 m
3
/h
or
■
Approx. 30 % higher than "Flow rate, nominal ven-
tilation 7D0B"
Setting in m
3
/h
7D0F Min. supply air temperature for bypass
Vitovent
200-C 300-C 300-W
X — —
To prevent unwanted formation of condensate on the
supply air lines, the bypass for passive cooling is only
enabled under the following conditions:
Parameter settings
7D08 Set extract air temperature
5816558
Parameter
