32
Vitovent
200-C 300-C 300-W
— X —
Switching voltage for the CO
2
signal with a connected
CO
2
/humidity sensor (accessories):
If the voltage at input X15.1/X15.2 on the control PCB
of the ventilation unit exceeds the set value, the air
flow rate is decreased. Below this limit the most recent
applicable air flow rate is reactivated.
Recommended setting: "40" (
≙
4 V)
Setting 1 ≙ 0.1 V
C1C1 Min. voltage, input 2 !
Vitovent
200-C 300-C 300-W
— X —
Switching voltage for the humidity signal with a con-
nected CO
2
/humidity sensor (accessories):
If the voltage at input X15.3/X15.4 on the control PCB
of the ventilation unit exceeds the set value, the air
flow rate is decreased. Below this limit the most recent
applicable air flow rate is reactivated.
Recommended setting: "80" (≙ 8 V)
Setting 1 ≙ 0.1 V
Note
If humidity control via the central humidity sensor is
simultaneously active ("Humidity sensor C105"):
Control via the central humidity sensor has priority.
C1C7 Flow rate correction !
Vitovent
200-C 300-C 300-W
— X —
Percentage correction factor for the air flow rate. This
affects the selected set air flow rates for all ventilation
levels, e.g. for balancing out system-based pressure
drops in the ductwork.
Setting in %
C1C8 CO2 sensor 1 min PPM !
Vitovent
200-C 300-C 300-W
— — X
Lower limit for air flow rate control depending on the
CO
2
concentration measured at CO
2
sensor 1:
If the measured CO
2
concentration is between the set
value and "CO2 sensor 1 max PPM C1C9", the venti-
lation unit can automatically and continuously adjust
the air flow rate depending on the measured value.
Setting in ppm (parts per million)
C1C9 CO2 sensor 1 max PPM !
Vitovent
200-C 300-C 300-W
— — X
Upper limit for air flow rate control depending on the
CO
2
concentration measured at CO
2
sensor 1:
If the measured CO
2
concentration is between "CO2
sensor 1 min PPM C1C8" and the set value, the ven-
tilation unit can automatically and continuously adjust
the air flow rate depending on the measured value.
Setting in ppm (parts per million)
Parameter settings
C1B1 Min. voltage, input 1 !
