Equipment required
ID: 4605355_1304_03
Pos. Designation Part no.
Heat pump
1
Heat pump See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1B Standard delivery pos. 1
3
Outside temperature sensor ATS Standard delivery pos. 2
4
Instantaneous heating water heater (accessory, with switching module) See Viessmann pricelist
6
Secondary pump UP See Viessmann pricelist
7
Circulation pump for cylinder heating UPSB See Viessmann pricelist
9
Heat pump See Viessmann pricelist
qP
Secondary pump UP, stage 2 See Viessmann pricelist
qQ
Circulation pump for cylinder heating, UPSB, stage 2 See Viessmann pricelist
qW
Safety equipment block with safety assembly 7143 779
qE
Expansion vessel secondary circuit See Vitoset pricelist
Primary circuit
5
Primary pump UP, stage 1 7452 617
qZ
Flow temperature sensor primary circuit Standard delivery
qU
Return temperature sensor, primary circuit Standard delivery
wP
Brine accessory pack See Viessmann pricelist
wQ
Pressure switch, primary circuit (option) 9532 663
wW
Brine distributor for geothermal probes/geothermal collectors See Viessmann pricelist
wT
Primary pump UP, stage 2 7452 617
wU
Geothermal probe/geothermal collector on site
DHW heating
eP
DHW cylinder See Viessmann pricelist
eW
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP on site
Heating water buffer cylinder
zP
Heating water buffer cylinder See Viessmann pricelist
zQ
Buffer temperature sensor PTS 7170 965
zW
Flow temperature sensor VTS system 7426 133
Heating circuit with mixer M2
uP
Underfloor heating circuit See Vitoset pricelist
uE
Temperature limiter to restrict the maximum temperature of underfloor heating systems 7151 728 or 7151 729
uR
Flow temperature sensor VTS 7183 288
uZ
Heating circuit pump UP M2 on site
uU
Mixer motor M2 7450 657
Active cooling function (AC)
iP
AC-Box (active cooling) 7245 606
iQ
Separate cooling circuit on site
iW
Fan convector with condensate drain See Viessmann pricelist
iE
Flow temperature sensor VTS, separate cooling circuit 7183 288
iR
Circulation pump, UP AC on site
iT
Contactor relay K1 7814 681
iZ
Room temperature sensor, separate cooling circuit 7408 012
Heating circuit without mixer A1
oP
Radiator heating circuit See Vitoset pricelist
oZ
Heating circuit pump UP A1 on site
Accessories (optional)
8
KM BUS distributor (if there is more than one KM BUS subscriber) 7415 028
oQ/
uQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
-Wireless base station Z011 413
-Vitotrol 200 RF wireless remote control Z011 219
-Wireless repeater 7456 538
oI
LON communication module 7172 173
qXP
Vitocom 100, type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100, type LAN 1 with communication module Z011 224
qXW
Vitocom 200, type LAN 2 with communication module Z011 390
qXE
Vitocom 200, type GP 3 with communication module with SIM card Z011 392
qXR
Vitocom 300, type LAN 3 with LON communication module Z011 399
qXT
Vitocom 300, type GP 4 with LON communication module Z011 400
Vitocal 300-G/350-G
(cont.)
