Equipment required
ID: 4605350_1304_03
Pos. Designation Part no.
1
Heat pump See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1B Standard delivery pos. 1
4
Instantaneous heating water heater See Viessmann pricelist
5
Primary pump (integrated for type BWC) See Viessmann pricelist
6
Secondary pump (integrated for type BWC) See Viessmann pricelist
7
Circulation pump for cylinder heating UPSB (integrated for type BWC) See Viessmann pricelist
8
Safety equipment block with safety assembly (integrated for type BWC) 7143 779
9
Expansion vessel secondary circuit See Vitoset pricelist
qP
Outside temperature sensor ATS Standard delivery pos. 4
qW
Geothermal probe/geothermal collector on site
qE
Brine distributor for geothermal probes/geothermal collectors See Viessmann pricelist
qR
Brine accessory pack See Viessmann pricelist
qT
Pressure switch, brine circuit 9532 663
DHW heating
wP
DHW cylinder See Viessmann pricelist
wQ
Cylinder temperature sensor STS 7170 965
wW
DHW circulation pump ZP on site
Heating/cooling circuit without mixer A1
eP
Underfloor heating circuit/cooling circuit A1 See Vitoset pricelist
eQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
-Wireless base station Z011 413
-Vitotrol 200 RF wireless remote control Z011 219
-Wireless repeater 7456 538
eW
Overflow valve on site
eE
Temperature limiter to restrict the maximum temperature of underfloor heating systems (option-
al)
7151 728 or 7151 729
qCP
Connection module with single room control, heating/cooling with pump logic 7247 845
qCQ
Room thermostat (installation on finished walls), heating/cooling RTR-E 6726 7247 853
qCW
Thermal actuator TS 5.11/230 (N/C, cores can be interchanged)
or
Thermal actuator TS+ 5.11/230 (N/C, cores can be interchanged)
7373 722
7419 860
Natural cooling function (NC)
rP
NC-Box with mixer Z009 565
rQ
Primary cooling circuit pump Standard delivery pos. 40
rW
Secondary cooling circuit pump Standard delivery pos. 40
rE
Contact humidistat Standard delivery pos. 40
rR
Mixing valve Standard delivery pos. 40
rT
2-way valve Standard delivery pos. 40
rZ
3-way diverter valve Standard delivery pos. 40
iO
Flow temperature sensor VTS NC 7183 288
Accessories (optional)
qQ
KM BUS distributor (if there is more than one KM BUS subscriber) 7415 028
oI
LON communication module 7172 173
qXP
Vitocom 100, type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100, type LAN 1 with communication module Z011 224
qXW
Vitocom 200, type LAN 2 with communication module Z011 390
qXE
Vitocom 200, type GP 3 with communication module with SIM card Z011 392
qXR
Vitocom 300, type LAN 3 with LON communication module Z011 399
qXT
Vitocom 300, type GP 4 with LON communication module Z011 400
Vitocal 300-G/350-G
(cont.)
