Required parameter settings
ID: 4605352_1304_03
Vitotronic 200, type WO1B
Parameter Value Function
7000 10 With heating circuit A1/HC1, M2/HC2, M3/HC3, DHW cylinder
7B00 1 Enable external heat source, oil/gas
7B0D 1 Enable external heat source for DHW
7100 2 Natural cooling NC-Box with mixer
7101 2 Natural cooling via heating circuit M2
7103 180 Min. flow temperature, cooling
7104 50 Influence room temperature hook-up cooling circuit
7010 1 External H1 extension (swimming pool heating)
7111 4 Cooling curve slope
7008 1 Swimming pool connected and heated
7A00 1 With Vitosolic 100, type SD1
3003 1 Vitotrol 200A remote control activated for heating circuit M2/HC2
ID: 4605352_1304_03
Vitosolic 100, type SD1
Parameter Value Function
ANL 1 System version
"RPM" "0" Pump with electronic speed control (delivered condition)
"1" Standard solar circuit pump without separate variable speed control - speed controlled by
pulse pack control
"2" Pump with PWM input (Wilo)
"3" Pump with PWM input (Grundfos)
ID: 4605352_1304_03
Vitotronic 200, type KO1B / KO2B / KW6B
Parameter Value Function
General 3A : 3 Blocking of the external heat source
General 3b : 2 External demand
General 9b : 70 Set value for external demand
Vitocal 300-G/350-G
(cont.)
System examples
VIESMANN
87
5822 472 GB
