Vitocal 222-GHeat pumps
Vitocal 222-G
1
DHW cylinder
2
High efficiency heat pump coil
3
Heat pump control unit Vitotronic 200
4
Circulation pump, primary
5
Circulation pump, secondary
6
Diverter valve, heating/DHW
7
Heat pump refrigerant circuit
Natural heat for family homes
The Vitocal 222-G is a compact heat pump
specifically designed for family homes. With a
modest footprint of 0.4m
2
, it takes up very
little space. It offers a high level of DHW
convenience, thanks to its 170 litre DHW
cylinder which is heated via an internal
indirect coil.
Extremely easy to operate
Like all compact appliances, the Vitocal 222-G
is equipped with the new user-friendly
Vitotronic control unit. If in doubt, help is
available at the push of a button. The graphic
interface will also display heating curves and
switching times. The programming unit of the
Vitotronic control unit can be removed from
the front of the appliance and be replaced with
an external programming unit. A five metre
long power cable enables the external
programming unit to be mounted almost
anywhere in a convenient position on a wall
mounting base.
Particularly quiet operation
The new three-dimensional anti-vibration
mounts make these compact heat pumps
particularly quiet so that they can be installed
close to the living space.
Compact and ready to connect
The heat pump is supplied by the factory ready
to connect, with a casing that can be taken
apart for easier handling. Variable connection
accessories ensure an easy installation on site.
Heating naturally? Cooling too, of course
With your compact heat pump, your low
energy house will always feel comfortable,
even in hot summers. The natural cooling
function brings cool underground temperatures
into your home. For this, you need the
Viessmann NC-Box as an accessory.
