Technical Data
6
6 VITOCELL 100-V
Domestic hot water draw rate
Storage tank contents heated to 140 °F / 60 °C, boiler not reheating
Storage capacity USG
ltr
42
160
53
200
79
300
119
450
DHW draw rate GPM
ltr/min
2.6
10
2.6
10
4.0
15
4.0
15
Domestic hot water draw
Water with t = 140 °F /
60 °C (constant)
USG
ltr
32
120
38
145
63
240
111
420
Percentage tank volume 75% 73% 80% 93%
Heat-up time
The stated heating times are achieved when the maximum recovery rate of the domestic hot water tank is made available at the respective
supply temperature and with a domestic hot water rise from 50 to 140 °F / 10 to 60 °C.
Storage capacity USG
ltr
42
160
53
200
79
300
119
450
Heating water supply temperature Heat-up time (minutes)
194 °F / 90 °C
176 °F / 80 °C
158 °F / 70 °C
19
24
34
19
24
37
23
31
45
28
36
50
Pressure drop on heating water side (primary circuit) Pressure drop on domestic hot water side
(secondary circuit)
42 USG / 160 ltr and 53 USG / 200 ltr storage capacities
79 USG / 300 ltr storage capacity
119 USG / 450 ltr storage capacity
5
1
6
7
5
1
8
v
2
.
3
Pressure drop
8 20
0.8 2
1.2 3
1.6 4
2 5
2.4 6
3.2 8
4 10
0.4 1
40 100
32 80
24 60
20 50
16 40
12 30
“ w.c. mbar
Flow rate
ltr/min
GPM
67
18
8
2.2
13
3.5
17
4.4
33
8.8
10
2.6
50
13
100
26
83
22
Pressure drop
120 300
160 400
80 200
40 100
32 80
24 60
20 50
16 40
12 30
8 20
4 10
3.2 8
2.4 6
2 5
1.6 4
200 500
Flow rate
2.2 500 2.6 600 3.5 800 4.4 1 000
9 2 000
13 3 000 18 4 000 22 5 000 26 6 000 31 7 000
ltr/h
GPM
“w.c. mbar
