28
]
[English]KEN001AKI 18.09.2017 • v09
L1 L2 L3 N L1 L2 L3 NL1 L2 L3 N
Viesta I4Z, Viesta I3Z Viesta I2Z
220V~ / 32A 220V~ / 16A2 x 220V~ / 16A
• If the cable is damaged or to be replaced, the operation must be carried out
the by after-sale agent with dedicated tools to avoid any accidents.
• If the appliance is being connected directly to the mains an omnipolar
circuit-breaker must be installed with a minimum opening of 3mm between
contacts.
• The installer must ensure that the correct electrical connection has been made
and that it is compliant with safety regulations.
• The cable must not be bent or compressed.
• The cable must be checked regularly and replaced by authorised technicians
only.
Installation
L
N
L
N
LL
N
black, brown
brown
black
brown
blue, grey
blue
blue, grey
green-yellow
green-yellow
green-yellow
