< Table 4. > RGB -PC Signal Resolution
No Resolution H-freq(KHz) V-freq.(Hz) Pixel clock Proposed
(MHz)
1. 640x350 31.469 70.08 25.17 DOS
2. 720x400 31.469 70.08 28.32 DOS
3. 720x400 37.927 85.03 35.50 DOS
4 640x480 31.469 59.94 25.17 VESA(VGA)
5. 640x480 37.861 72.80 31.50 VESA(VGA)
6. 640x480 37.500 75.00 31.50 VESA(VGA)
7. 640x480 43.269 85.00 36.00 VESA(VGA)
8. 800x600 35.156 56.25 36.00 VESA(SVGA)
9. 800x600 37.879 60.31 40.00 VESA(SVGA)
10. 800x600 48.077 72.18 50.00 VESA(SVGA)
11. 800x600 46.875 75.00 49.50 VESA(SVGA)
12. 800x600 53.674 85.06 56.25 VESA(SVGA)
13. 832x624 49.725 74.55 57.28 Macintosh
14. 1024x768 48.363 60.00 65.00 VESA(XGA)
15. 1024x768 56.476 70.06 75.00 VESA(XGA)
16. 1024x768 60.023 75.02 78.75 VESA(XGA)
17. 1024x768 68.677 85.00 95.62 VESA(XGA)
18. 1280x768 47.693 60.0 80.12 VESA(WXGA)
19. 1280x768 60.091 75.0 102.87 VESA(WXGA)
20. 1280x768 68.504 85.0 118.37 VESA(WXGA)
21. 1280x1024 64.000 60.00 108.000 VESA(SXGA)
22. 1280x1024 74.405 69.99 125.000 VESA(SXGA)
23. 1280x1024 80.000 75.00 135.000 VESA(SXGA)
24. 1280x1024 91.100 85.00 157.500 VESA(SXGA)
25. 1600x1200 75.000 60.00 162.000 VESA(UXGA)
