57
REPLACEMENT PARTS LIST
CONNECTOR EARPHONE JACK (UEJ-CV-003) P203;
CONNECTOR DVI DVI CONNECTOR 440062-1 ==> AMP P201;
TRANSFORMER,SMPS[COIL] EPC1716 650UH +-15%, DC-DC CON. T800;
PLCC AMP (SOCKET) 822473-3 AMP 32PIN 2.54MM NIKEL PLCC IC601;
IC FLASH MEMORY AM29LV040B(PLCC) 4Mb AMD IC601;
CONNECTOR D_SUB D_SUB FEMALE 15P 3ROW R/A P200;
WAFER SMW200-03P (DIP), YEONHO P304;
WAFER SMW200-10P (DIP), YEONHO P104_M;
WAFER SMW200-12P (DIP), YEONHO P806;
WAFER SMW200-15P (DIP), YEONHO P807;
WAFER SMW250-03P (DIP), YEONHO P701;
WAFER SMW250-04P (DIP), YEONHO P700;
POWER INDUCTOR 33uH, CPS-01-330(CH-8010S), GET 170 L701,L702,L805;
CRYSTAL HC49U KJE RADIAL 14.31818MHz +/-30 PPM X400;
CHIP RESISTOR 0 OHM 1/8W 2012 5% D (000) R380, R381, R382, R390, R391, R392,
R393, R394, R395, R396, R397, R402,
R404, R407, R409, R411, R414, R416,
R501, R503, R813, R823;
CHIP RESISTOR 10 OHM 1/8W 2012 5% D (100) R746, R747, R748, R749, R750, R751,
R752, R753;
CHIP RESISTOR 22 OHM 1/8W 2012 5% D (220) R368, R600, R601, R603, R604;
CHIP RESISTOR 33 OHM 1/8W 2012 5% D (330) R423, R434, R445, R446;
CHIP RESISTOR 180 OHM 1/8W 2012 5% D (181) R504, R505;
CHIP RESISTOR 1.5K OHM 1/8W 2012 5% D (152) R808;
CHIP RESISTOR 82 OHM 1/8W 2012 5% D (820) R141, R143, R144, R802;
CHIP RESISTOR 100 OHM 1/8W 2012 5% D (101) R154, R155, R313, R315, R316, R345,
R346, R347, R354, R358, R383, R413,
R418, R807, R815, R905;
CHIP RESISTOR 160 OHM 1/8W 2012 5% D (161) R805;
CHIP RESISTOR 220 OHM 1/8W 2012 5% D (221) R800;
CHIP RESISTOR 390 OHM 1/8W 2012 5% D (391) R401;
CHIP RESISTOR 470 OHM 1/8W 2012 5% D (471) R148, R149, R508;
CHIP RESISTOR 1K OHM 1/8W 2012 5% D (102) R102, R103, R104, R221, R312, R322,
R435, R444, R520, R521, R523;
CHIP RESISTOR 1M OHM 1/8W 2012 5% D (105) R502;
CHIP RESISTOR 2K OHM 1/8W 2012 5% D (202) R217, R218;
CHIP RESISTOR 2.7K OHM 1/8W 2012 5% D (272) R384, R385;
CHIP RESISTOR 3.3K OHM 1/8W 2012 5% D (332) R321;
CHIP RESISTOR 3.6K OHM 1/8W 2012 5% D (362) R133, R135, R137;
CHIP RESISTOR 4.7K OHM 1/8W 2012 5% D (472) R134, R136, R138, R207, R208, R310,
R311, R319, R320, R331, R341, R342,
R352, R500, R524, R525, R801;
CHIP RESISTOR 8.2K OHM 1/8W 2012 5% D (822) R105, R107, R109;
CHIP RESISTOR 10K OHM 1/8W 2012 5% D (103) R106, R108, R110, R417;
CHIP RESISTOR 24K OHM 1/8W 2012 5% D (243) R806;
Item Specification Location
LC-32IE11_MAIN (MANUAL INSERT)
MAIN ASS'Y LC-32IE11_LPL_MAIN PCB ASS`Y
LC-32IE11_MAIN (SMD_BOTTOM)
To Next Page
