Viewpia LC-32IC10 - Page 59

59
RADIAL REGISTER 4.7 OHM 2 W 5.00% R398, R455;
CAPACITOR,FIXED FILM 0.22uF 63V 5% PCMT 365 C731, C732;
AL EL CAPACITORS 1uF STD 50V M FL TP5 (5X11 85°C) C823;
AL EL CAPACITORS 4.7uF STD 50V M FL TP5 (5X11 85°C) C323, C340, C703, C704;
AL EL CAPACITORS 10uF STD 16V M FL TP5 (5X11 85°C) C920, C921;
AL EL CAPACITORS 10uF STD 50V M FL TP5 (5X11 85°C) C109, C110, C111, C118, C119, C120,
C313, C314, C315, C334, C337, C345,
C368, C374, C375, C378, C496, C549,
C550, C711, C712, C825, C910, C914,
C917;
AL EL CAPACITORS 47uF STD 16V M FL TP5 (5X9 85°C) C127, C201, C203, C210, C310, C497;
AL EL CAPACITORS 47uF STD 50V M FL TP5 (6.3X11 85°C) C493, C700;
AL EL CAPACITORS 100uF STD 16V M FL TP5 (6.3X11 85°C) C108, C384, C400, C405, C406, C441,
C448, C450, C451, C468, C479, C480,
C481, C482, C483, C502, C503, C512,
C513, C601, C602, C603, C604, C610,
C611, C846, C847, C849, C900, C912,
C918, C922, C929, C931;
AL EL CAPACITORS 220uF STD 10V M FL TP5 (6.3X11 85°C) C302, C303, C359, C381;
AL EL CAPACITORS 220uF STD 16V M FL TP5 (8X11.5 85°C) C403;
AL EL CAPACITORS 220uF STD 25V M FL TP5 (8X11.5 85°C) C801, C803, C804;
AL EL CAPACITORS 220uF STD 50V M FL TP5 (10X16 85°C) C802;
AL EL CAPACITORS 470uF STD 16V M FL TP5 (10X12.5 85°C) C810, C824, C838;
AL EL CAPACITORS 470uF STD 35V M FL TP5 (10X16 85°C) C716, C717, C733, C734, C736, C737,
C743, C745, C821, C840;
Item Specification Location
LC-32IE11_MAIN (AUTO INSERT_RADIAL)
RADIAL REGISTER 4.7 OHM 2 W 5.00% R398, R455;
CAPACITOR,FIXED FILM 0.22uF 63V 5% PCMT 365 C731, C732;
AL EL CAPACITORS 1uF STD 50V M FL TP5 (5X11 85°C) C823;
AL EL CAPACITORS 4.7uF STD 50V M FL TP5 (5X11 85°C) C323, C340, C703, C704;
AL EL CAPACITORS 10uF STD 16V M FL TP5 (5X11 85°C) C920, C921;
AL EL CAPACITORS 10uF STD 50V M FL TP5 (5X11 85°C) C109, C110, C111, C118, C119, C120,
C313, C314, C315, C334, C337, C345,
C368, C374, C375, C378, C496, C549,
C550, C711, C712, C825, C910, C914,
C917;
AL EL CAPACITORS 47uF STD 16V M FL TP5 (5X9 85°C) C127, C201, C203, C210, C310, C497;
AL EL CAPACITORS 47uF STD 50V M FL TP5 (6.3X11 85°C) C493, C700;
AL EL CAPACITORS 100uF STD 16V M FL TP5 (6.3X11 85°C) C108, C384, C400, C405, C406, C441,
C448, C450, C451, C468, C479, C480,
C481, C482, C483, C502, C503, C512,
C513, C601, C602, C603, C604, C610,
C611, C846, C847, C849, C900, C912,
C918, C922, C929, C931;
AL EL CAPACITORS 220uF STD 10V M FL TP5 (6.3X11 85°C) C302, C303, C359, C381;
AL EL CAPACITORS 220uF STD 16V M FL TP5 (8X11.5 85°C) C403;
AL EL CAPACITORS 220uF STD 25V M FL TP5 (8X11.5 85°C) C801, C803, C804;
AL EL CAPACITORS 220uF STD 50V M FL TP5 (10X16 85°C) C802;
AL EL CAPACITORS 470uF STD 16V M FL TP5 (10X12.5 85°C) C810, C824, C838;
AL EL CAPACITORS 470uF STD 35V M FL TP5 (10X16 85°C) C716, C717, C733, C734, C736, C737,
C743, C745, C821, C840;
LC-32IE11_MAIN (AUTO INSERT_RADIAL)
PCB MAIN B/D 2005.03.30 Rev. 1.1
CHIP RESISTOR 0 OHM 1/10W 1608 5% D (000) R165, R399, R343, R400, R403, R406,
R408, R410, R412, R415, R428, R431,
R432, R433, R436, R437, R438, R439,
R440, R443, R510, R513;
CHIP RESISTOR 22 OHM 1/10W 1608 5% D (220) R447, R448, R449;
CHIP RESISTOR 75 OHM 1/10W 1608 5% D (750) R202, R203, R206;
CHIP RESISTOR 82 OHM 1/10W 1608 5% D (820) R111, R112, R113, R117, R118, R119,
R120, R121, R124, R125, R126, R128,
R129, R139, R140, R142;
CHIP RESISTOR 100 OHM 1/10W 1608 5% D (101) R151, R152, R153, R156, R200, R201,
R219, R220, R301, R302, R304, R305,
R307, R317, R318, R337, R338, R339,
R340, R348, R349, R351, R353, R355,
R371, R372, R386, R405, R453, R454,
R607, R901, R902;
CHIP RESISTOR 150 OHM 1/10W 1608 5% D (151) R605, R700, R702;
CHIP RESISTOR 220 OHM 1/10W 1608 5% D (221) R210, R211, R212,R213;
CHIP RESISTOR 270 OHM 1/10W 1608 5% D (271) R114, R115, R116;
CHIP RESISTOR 470 OHM 1/10W 1608 5% D (471) R122, R123, R127, R145, R146, R147,
R150;
LC-32IE11_MAIN (SMD_TOP)
