Viewpro A30TR - Control Box Printing (Standard Version)

To Next Page

To Previous Page

[1] Control box

[2] Upper damping board

[3] Lower damping board

[4] FHD zoom camera

[7] Damping ball

[8] Yaw axis motor

[9] Roll axis motor

[10] TF card slot

[11] Pitch axis motor

[12] 3-6S power interface

[13] Micro HDMI interface

[15] Viewport unlock button

[14] Ethernet interface

[5] Infrared thermal camera

[6] laser rangefinder

2.2.1 Control Box Printing (Standard Version)

PITCH

Yellow Jumper Cap

GND

YAW

MODE

ZOOM

CUS

PIC/REC

MULTI

USB

5V output

GND

1 2 3

Please ensure that there isn’t any obstacle while the

motor rotating.

Please remove the obstacle immediately if gimbal

camera is blocked during rotation.

Don't use laser ranging against glass within 5meters.

Don’t put the infrared thermal camera towards the sun,

magma, laser, etc. in case any burn to the camera.
