Commercial Display RS-232 Protocol
Revision 1.x
________________________________________________________________
May 28, 2007 5 / 16 Commercial Display RS-232 Protocol
001: ON
status: ON or
Standby
Input Select
8
s
“
22
000 : VGA
001 : HDMI
002 : DVI-D
003 : AV
004 : YPbPr
005 : S-Video
Contrast
8
s
#
23
000 ~ 100
Brightness
8
s
$
24
000 ~ 100
Sharpness
8
s
%
25
000 ~ 100
Color
8
s
&
26
000 ~ 100
Tint
8
s
„
27
000 ~ 100
Bass
8
s
.
2E
000 ~ 100
Sets Bass value
Treble
8
s
/
2F
000 ~ 100
Sets Treble value
Balance
8
s
0
30
000 ~ 100
Sets Balance
position
Picture Size
8
s
1
31
000 : FULL
001 : NORMAL
002 : CUSTOM
003 : DYNAMIC
004 : REAL
OSD Language
8
s
2
32
000 : English
001 : French
002 : Spanish
003 : Germany
004 : Italian
005 : Simplified
Chinese
006 : Russian
007 : Polish
008 : Turkish
OSD timeout
8
s
3
33
005 ~120 Sec
Set OSD timeout
Volume
8
s
5
35
000 ~ 100
Mute
8
s
6
36
000: OFF
001: ON (mute)
Off Timer
8
s
7
37
000: OFF
001~024 (hour)
PIP Mode
8
s
9
39
000 : OFF
001: PIP
002: POP
003 : PBP
004 : PBPA
PIP Sound select
8
s
:
3A
000: Main
001: PIP
PIP position
8
s
;
3B
000: Up
001: Down
002: Left
003: Right
PIP Input
8
s
<
3C
000 : VGA
001 : HDMI
002 : DVI-D
003 : AV
004 : YPbPr
