ViewSonic E70F - 17" CRT Display User Manual

8.2.4 PICTURE TILT.
2mm
230mm
310mm
h<
8.3 LINEARITY
APPLY SIGNAL D AT ALL MODE, INPUT CROSS-HATCH PATTERN
8.4 CENTERING (WITH MAGNETIC FIELD)
8.4.1 APPLY SIGNAL D AT ALL MODES.
8.4.2 PICTURE POSITION
I
A – B
I
<
3mm.
I C – D I <
3mm.
I
A – B
I
<
4mm.
I C – D I <
4mm.
H-Linearity: (Hmax-Hmin)*100%
(Hmax+Hmin)
V
-Linearity:
(Vmax-Vmin)*100%
(Vmax
+
Vmin)
<
4%
<
4%
Primary
Primary
d
5% Others
C
D
B
A
BAZEL
Prima
Other
9. HORIZONTAL SWEEP
9.1 PULL-IN RANGE
9.1.1 APPLY SIGNAL D WITH A HORIZONTAL FREQUENCY OF 30KHZ MODE, MONITOR MUST BE
IN SYNC.
9.1.2 APPLY SIGNAL D WITH A HORIZONTAL A HORIZONTAL FREQUENCY OF 70KHZ MODE,
MONITOR MUST BE IN SYNC.
8
ViewSonic Corporation Confidential
-
Do Not Copy 70f+SB-3E
