Item Revision History ViewSonic P/N Reference P/N Description Location Universal number# Lead time
1 E-IC-0401-0985 2510005310 IC PWM 8PIN IC101 UC3843BN 4 WEEKS
2 E-IC-0401-2852 2610185342 IC EEPROM 8K 8PIN IC302 M24C08BN6 4 WEEKS
3 E-IC-0401-2275 2530095106 IC DEFLECTION PROCESSOR SDIP-32P IC401 TDA9113 4 WEEKS
4 E-IC-0401-2730 2530026104 IC VERT DEFLECTION SIP-10P IC501 KA2142 4 WEEKS
5 E-IC-0401-2393 2530159004 IC RGB VIDEO PRE-AMP 24PIN IC601 LM1269 4 WEEKS
6 E-IC-0401-4003 2530159104 IC WB AMP DRIVER RGB CRT TO-220-9P IC602 LM2460TA 4 WEEKS
7 E-IC-0401-4004 2500165111 IC 120V TRIPLE BIAS CLAMP DIP-8P IC603 LM2479NA 4 WEEKS
8 E-IC-0401-2731 2530211226 IC MASK OSD CONTROLLER DIP-20P IC604 NT68295-90049 4 WEEKS
9 E-Q-0402-0156 242017400006 FET 600V 6A 1.25ohm TO-220F Q101 2SK2545 2 WEEKS
10 E-Q-0402-1453 210106300017 TR 350V 0.5A TO-92 30-200 Q102 2N6517TA 2 WEEKS
11 E-Q-0402-1432 242016350517 FET 250V 8.1A 0.45ohm TO-220F Q202 IRFS634B 2 WEEKS
12 E-Q-0402-1588 211162030006 TR -40V -3A 2-8H1A 120-240 Q203 2SA1359-Y 2 WEEKS
13 E-Q-0402-1455 211102500117 TR -50V -0.15A TO-92 200-240 Q205 KSA1015GRTA 2 WEEKS
14 E-Q-0402-1454 210231010011 TR 20V 1A TO-92MOD 120-240 Q206 2SD468CTZ 2 WEEKS
15 E-Q-0402-1452 210057920017 TR 750V 12A TO-3PF 10 Q401 FJAF6812TU 2 WEEKS
16 E-Q-0402-1206 210233510011 TR 80V 1A TO-92MOD 100-200 Q402 2SD667CTZ 2 WEEKS
17 E-Q-0402-0888 211106000106 TR -300V -0.05A TO-92 40 Q404 BF421(TPE2) 2 WEEKS
18 E-Q-0402-1451 210013030006 TR 60V 3A 2-10R1A 100-320 Q409 2SD2012 2 WEEKS
19 E-Q-0402-1208 211105700006 TR -250V -0.05A 2-5F1B 50 Q419 BF423(TPE2) 2 WEEKS
20 E-Q-0402-1207 210105700006 TR 250V 0.05A TO-92 50 Q501 BF422(TPE2) 2 WEEKS
21 E-R-0405-6645 190204200 RES FUSING MF 1/2W .1 J R114 RF50ST52A0.1OHMJ 2 WEEKS
22 E-R-0405-0923 190200400 RES FUSING MF 1/2W .22 J SMALL R457 RFS12JR220A520NH 2 WEEKS
23 E-RL-0414-0074 720060701 RELAY 240VAC/12VDC 5A DPST TV4 RL101 OSA-SS-212DM5 2 WEEKS
24b Removed 04/19/04 E-RL-0414-0106 720840115 RELAY 125VAC/12VDC 10A SPDT RL401 833H-1C-C 2 WEEKS
24c Added 04/19/04 E-RL-0414-0123 720840115 RELAY 125VAC/12VDC 10A SPDT RL401 833H-1C-C 2 WEEKS
25 E-T-0408-0519 2801427200 X'FMR SMT 250uH J T101 SMT-35RV-315T 2 WEEKS
26 E-FBT-0406-0237 2850008610 FBT 17" 70KHZ 1.24mH T401 CF1803DE2700 2 WEEKS
27b Removed 04/19/04 E-YK-0413-0060 736000026 RESONATOR 12.00MHZ +/-0.1% 2P 10*10 Y301 ZTA12.00MX010 2 WEEKS
27c Added 04/19/04 E-X-0415-0134 736000026 RESONATOR 12.00MHZ +/-0.1% 2P 10*10 Y301 ZTA12.00MX010 2 WEEKS
28 A-PC-0106-0150 3090107600 AC POWER CORD L1800 BLACK P-model 2 WEEKS
29 A-PC-0106-0254 3090130400 AC POWER CORD L1800 BLACK P-model to pc 2 WEEKS
30 M-LB-0813-0925 3201969100 LABEL ID 65*75 E70F+ P-model 2 WEEKS
31 PL-TB-0717-0148 3360318700 SWIVEL ABS EP32 S7SB1EL 2 WEEKS
32 C-BS-0303-0397 3360425000 BASE ABS 41 S7SB1EL 2 WEEKS
33 C-BC-0302-0525 3368214601 R/C ASSY J770SCM03C S7RB1AT 2 WEEKS
34 M-MS-0808-7805 3360506500 LED LENS PMMA NAT Y0-487 S7FB2AT 2 WEEKS
35 PL-NB-0707-0196 3360625100 POWER KNOB ABS 41 S7PFB1AT 2 WEEKS
36 PL-FK-0709-0120 3360728400 FUNCTION KEY ABS 41 S7PFB1AT 2 WEEKS
37 C-FP-0301-0958 3361088601 F/B ABS SILVER E71F+SB-3 S7PFB1AT 2 WEEKS
38 P-FM-0602-0849 3500102102 END BLOCK TOP J770SCM00A 400/40' 2 WEEKS
39 P-FM-0602-0850 3500102202 END BLOCK BOTTOM J770SCM00A 400/40' 2 WEEKS
40 P-BX-0601-0942 3512256700 CARTON 460*459*450 M/P/G--model 2 WEEKS
41 A-CD-E70F+SB-3 3532080300 CD-ROM E70FB J770SBM01C/02C/04C 2 WEEKS
42 M-MS-0808-8663 5011088200 MANUAL VSC E70-10G J770SAM06A 2 WEEKS
43 B-MB-0201-0830 5600010593 MAIN BOARD ASSY 2 WEEKS
44b Removed 04/19/04 A-VC-0101-0344 3080421200
D-SUB/HOUSING L=1500 IVO 4 WEEKS
44c Added 04/19/04 E-C-0404-4808 146421810428 CAP AL 450V 180U M 25*40 C101 450USR180MSTB40 2 WEEKS
45 Added 04/19/04 E-C-0404-5326 17D698AD26 CAP MP DP 1.5KVH 4.9KP H KI15 C401 MPPS492H3DC 2 WEEKS
46 Added 04/19/04 E-C-0404-2096 1751131C26 CAP MP DP 250V .22U J KI10 C413 MPA224J2EB 2 WEEKS
47 Added 04/19/04 E-C-0404-2096 1751131C26 CAP MP DP 250V .22U J KI10 C414 MPA224J2EB 2 WEEKS
48 Added 04/19/04 E-C-0404-5327 1751121C26 CAP MP DP 250V .1U J KI10 C415 MPA104J2EB 2 WEEKS
49 Added 04/19/04 E-C-0404-5328 1891040D26 CAP PP DP 800V 6.8KP J KI15 C416 PPN682J2KC 2 WEEKS
50 Added 04/19/04 E-C-0404-4512 1751271D06 CAP MP DP 250V .62U J KI15 C417 7U2E624J-ACE(PMS) 2 WEEKS
E70f+SB-3 RSPL
