F. REGULATORY REQUIREMENT:
1. SAFETY
1.1 UL
THE MONITOR SHALL BE APPROVED TO UL STANDARD UL1950.
1.2 CSA
THE MONITOR SHALL BE CERTIFIED TO CSA STANDARD CSA-CS22.2. NO.950.
1.2 TUV: 60950
1.3 IEC STANDARD: IEC60950
1.4 THE MONITOR SHALL MEET THE REQUIREMENTS AS FOLLOWS:
A) FCC RULES PART 15 SUBPART J FOR CLASS B.
B) CE: EN55022, EN55024
1.5 ERGONMICS
A) MPRII.
B) TUV/GS.
C) TCO99 (OPTION).
1.6 DIELECTRIC STRENGTH TEST:
THE MONITOR SHALL WITHSTAND A 2545 VDC / 3 SEC.
BETWEEN PRIMARY AND SECONDARY.
BETWEEN PRIMARY AND PROTECTIVE EARTHLING.
1.7 LEAKAGE CURRENT:
THE MAXIMUM CURRENT FLOWING IN THE FRAME / GROUND CONDUCTOR SHALL BE LESS THAN 0.75mA AT
110 / 240
VAC.
1.8 X-RADIATION:
ALL MONITORS MUST COMPLY WITH THE DHHS REGULATIONS CONCERNING X- RADIATION. THAT IS A
FAILURE CONDITION MUST BE SIMULATED THAT WOULD PRODUCE THE WORST CASE X-RAYS SHOULD NOT
MEASURE MORE THAN 0.5 MR / HR (MILLIRONTGEN PER HOUR) AT A DISTANCE OF TWO-INCHES ANYWHERE,
AROUND THE MONITOR.
G. APPENDIX:
APPEDNDIX A:
ALL SIGNALS MUST BE AVAILABLE WITH CHROMA 2135, 2250.
SIGNAL A FULL WHITE PATTERN.
SIGNAL B STAIRSTEP: 16 GRAY LEVELS INCLUDING BLACK AND WHITE ASCENDING FROM LEFT TO RIGHT IN
EQUAL PIXEL WIDTHS.
SIGNAL C COLOR BARS: EIGHT 100 PIXEL WIDE BARS.
SIGNAL D CROSSHATCH: 12 * 16 SQUARES.
SIGNAL E ACTIVE DISPLAY CONTAINS ALL CHARATERS “ME” ON WHITE BACKGROUND.
SIGNAL F 70mm x 70mm FIELD OF WHITE CENTERED IN THE MIDDLE OF THE SCREEN.
APPENDIX B:
TIMING OF INPUT SIGNALS. INPUT LEVEL SPECIFICATION.
A.INPUT LEVEL
ANALOG VIDEO
R.G.B: 0.7V ± 3DB
COMPOSITE SYNC
LOW (0) 0.00V MIN. 0.65V MAX.
HIGH (1) 2.40V MIN. 5.50V MAX
APPENDIX C: MAGNETIC FIELD
!
!
! !!!!!OPSUI!BNFSJDB!!!;!CI!>!361!,
!21NH-!CW!>!561!,!21!NH/!
EUROPE :BH=250+
10MG, BV = 450 + 10 MG.
ASIA :BH=400+
10MG, BV = 270 + 10 MG.
AUSTRALIA : BH = 270 +
10MG, BV = -570 + 10 MG.
CHINADOMESTIC :BH=340+
10MG, BV = 360 + 10 MG.
16
ViewSonic Corporation Confidential
-
Do Not Copy 70f+SB-3E
