MODE NO.
8 9 10 11 12
VESA VESA MAC VESA VESA
MODE NAME
800 X 1024 X 1024 X 1280 X 1024 X
600 768 768 1024 768
PIXEL CLOCK (MHZ)
56.25 78.75 80.000 108.000 94.500
HORIZONTAL FREQ (KHZ)
53.674 60.023 60.241 63.981 68.677
SYNC. POLARITY
++- ++
A H.TOTAL (us)
18.631 16.66 16.600 15.630 14.561
(PIXELS)
(1048 ) (1312 ) (1328 ) (1688 ) (1376 )
B H.SYNC (us)
1.138 1.219 1.2 1.037 1.016
(PIXELS)
(
64
)
(
96
)
(
96
)
(
112
)
(
96
)
C H.BACK PORCH (us)
2.702 2.235 2.2 2.296 2.201
(PIXELS)
(152) (176) (176) (248 ) (208 )
D H.ACTIVE (us)
14.222 13.003 12.8 11.852 10.836
(PIXELS)
(
800
)
(
1024
)
(
1024
)
(
1280
)
(
1024
)
E H.FRONT PORCH (us)
0.569 0.23 0.4 0.444 0.508
(PIXELS)
(32 ) (16 ) (32 ) (48 ) (48 )
VERTICAL FREQ(HZ)
85 75.029 74.927 60.200 85.000
SYNC. POLARITY
++- ++
O V.TOTAL (ms)
11.756 13.328 13.346 16.661 11.765
(LINES)
(631 ) (800 ) (804 ) (1066 ) (808 )
P V.SYNC (ms)
0.056 0.05 0.05 0.047 0.044
(LINES)
(3) (3) (3) (3) (3)
Q V.BACK PORCH (ms)
0.503 0.466 0.498 0.594 0.524
(LINES)
(27) (28) (30) (38 ) (36 )
R V.ACTIVE (ms)
11.179 12.795 12.749 16.005 11.183
(LINES)
(600 ) (768 ) (768 ) (1024 ) (768 )
S V.FRONT PORCH (ms)
0.019 0.017 0.05 0.016 0.015
(LINES)
(1) (1) (3) (1) (1)
18
