Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
143 #N/A 0013821000 RES CF 1/4W 820 J R433 RD 1/4W 820 JT 1
144 #N/A 0013821800 RES CF 1/4W 820 J SMALL R430 1
145 #N/A 0013822800 RES CF 1/4W 8.2K J SMALL R449 1
146 #N/A 0013913000 RES CF 1/4W 91K J R487 RD 1/4W 91K JT 1
147 #N/A 0023102000 RES CF 1/2W 1K J R218 1
148 #N/A 0023105000 RES CF 1/2W 1M J R101 RD 1/4W 1M JT 1
149 #N/A 0023108000 RES CF 1/2W 1 J R116 1
150 #N/A 0023150000 RES CF 1/2W 15 J R404 1
151 #N/A 0023158000 RES CF 1/2W 1.5 J R505 CR1/2W-SJ 1.5R 1
152 #N/A 0023184000 RES CF 1/2W 180K J R464 1
153 #N/A 0023188000 RES CF 1/2W 1.8 J R506 RD1/2WT52 1R8J 1
154 #N/A 0023224000 RES CF 1/2W 220K J R460 1
155 #N/A 0023271000 RES CF 1/2W 270 J R222 1
156 #N/A 0023273000 RES CF 1/2W 27K J R224 RD50ST52 27K J 1
157 #N/A 0023330000 RES CF 1/2W 33 J R108 RD 1/2W 33 JT 1
158 #N/A 0023331000 RES CF 1/2W 330 J R508 RD 1/2W 330R J T/B 1
159 #N/A 0023332000 RES CF 1/2W 3.3K J R407 1
160 #N/A 0023564000 RES CF 1/2W 560K J R104,R105 2
161 #N/A 0023623000 RES CF 1/2W 62K J R221 RD50ST52 62K J 1
162 #N/A 0023750000 RES CF 1/2W 75 J R223 1
163 #N/A 0111053800 RES MF 1/4W 5.6K F SMALL R507 1
164 #N/A 0111059000 RES MF 1/4W 10K F R428 SN1/4WT52F10K 1
165 #N/A 0111059800 RES MF 1/4W 10K F SMALL R640 SN1/4WST52 10K F 1
166 #N/A 0111070800 RES MF 1/4W 30K F SMALL R435 SN1/4WST52 30KOHM F 1
167 #N/A 0111170800 RES MF 1/4W 3.83K F SMALL R504 SN1/4WST52 3.83K F 1
168 #N/A 0111205800 RES MF 1/4W 6.81K F SMALL R447 SN1/4WST52 6.81K F 1
169 #N/A 111239800 RES MF 1/4W 3.16K F SMALL R446 1
170 E-R-0405-5090 111272800 RES MF 1/4W 51.1K F SMALL R436 1
171 #N/A 111302000 RES MF 1/4W 27.4K F R509 1
172 #N/A 111356800 RES MF 1/4W 24.3K F SMALL R227,R431 2
173 E-R-0405-6083 111392800 RES MF 1/4W 13.7K F SMALL R515 1
174 #N/A 111409800 RES MF 1/4W 6.49K F SMALL R432,R471 2
175 #N/A 133124000 RES MOF 1W 120K J R103 RSU01J 1203 A520 1
176 E-R-0405-5728 133152000 RES MOF 1W 1.5K J R219 1
177 E-R-0405-5729 133181000 RES MOF 1W 180 J R215,R421 BO1WJ0181 2
178 E-R-0405-6836 133302000 RES MOF 1W 3K J R4408,R489 RSN1WJ 3K T52 2
179 E-R-0405-4358 133339000 RES MOF 1W .33 J R203 1
180 E-R-0405-5735 133471000 RES MOF 1W 470 J R209 1
181 E-R-0405-6868 133510000 RES MOF 1W 51 J R420 RSN1WJ 51R T52 1
182 #N/A 143153200 RES MOF 2W 15K J VDK R102 1
183 E-R-0405-6818 143158200 RES MOF 2W 1.5 J VDK R213 RSU02J1R50 FB 1
184 E-R-0405-5954 143189000 RES MOF 2W .18 J R111 1
185 E-R-0405-5955 143271000 RES MOF 2W 270 J R408 1
186 E-R-0405-6454 143271200 RES MOF 2W 270 J VDK R425 1
187 #N/A 143391200 RES MOF 2W 390 J VDK R117 MOR2WJ 390R F1 1
188 E-R-0405-6840 143569200 RES MOF 2W .56 J VDK R403 1
189 E-R-0405-0923 190200400 * RES FUSING MF 1/2W .22 J SMALL R457 RFS12JR220A520NH 1
190 E-R-0405-6645 190204200 RES FUSING MF 1/2W .1 J R114 RF50ST52A0.1OHMJ 1
191 E-R-0405-5777 606113004 * RES VR VERT 0.1W 200 T VR401 VZ067TH1B201 1
192 E-R-0405-5386 606201004 * RES VR HORI 0.1W 1K T VR101,VR403 VZ067TL1B102 2
193 E-RL-0414-0074 720060701 * RELAY 240VAC/12VDC 5A DPST TV4 RL101 OSA-SS-212DM5 1
194 E-RL-0414-0106 720840115 * RELAY 125VAC/12VDC 10A SPDT RL401 833H-1C-C 1
195 E-YK-0413-0060 736000026 * RESONATOR 12.00MHZ +/-0.1% 2P 10*1 Y301 ZTA12.00MX010 1
196 E-FS-0410-0089 805340702 * FUSE TSC 4A 250V UL SEM PIG F101 0215004.MRET5 1
197 M-MS-0808-7471 900030118 * PTC R=8 OHM +/-20% 27A 2P PTC101 DGC2R08M 1
198 E-TH-0416-0111 911000216 * NTC R=10 OHM L 3A NTC101 SCK-103 1
199 E-SP-0417-0093 921220117 * SPARK GAP 1.2KV +-500V TP SG602 AG15PC122FB-K2M 1
200 E-SP-0417-0062 922010218 SPARK GAP 200VDC M TP SG601 DSP-201M-C04F 1
201 E-C-0404-3961 1101045032 * CAP Y CD 250VAC 1KP K B I CY101,CY102 CS10-B2GA102KYGS 2
202 E-C-0404-2541 1101046032 * CAP Y CD 250VAC 2.2KP M E I CY104 CS11-E2GA222MYGS 1
203 E-C-0404-4109 1101047032 * CAP Y CD 250VAC 3.3KP M E I CY106 CS13-E2GA332MYGS 1
204 E-C-0404-3640 1120018800 * CAP CD 100V 33P J C0G TP5 C306,C307 CHA4330JG1H 2
205 E-C-0404-3641 1120026800 * CAP CD 100V 68P J C0G TP5 C309,C419 CHA5680JG1H 2
206 E-C-0404-3720 1120030800 * CAP CD 100V 100P J C0G TP5 C448,C452,C615,C617 CHA6101JG1H 4
207 E-C-0404-3778 1120032800 * CAP CD 100V 120P J C0G TP5 C435 CHA7121JG1H 1
E-C-0404-3642 1122354800 * CAP CD 100V .01U M Z5U TP5 C104,C107,C405,C408, EA7103MG1H 6
#N/A C418,C442,C512,C601,
#N/A C602,C603,C604,C605,
#N/A C608,C623,C624,C625
209 E-C-0404-3646 1122942800 * CAP CD 100V 470P K Y5P TP5 C509,C631 BA4471KG1H 2
210 E-C-0404-3647 1122944800 * CAP CD 100V 680P K Y5P TP5 C434,C506 BA4681KG1H 2
211 E-C-0404-3648 1122945800 * CAP CD 100V 1KP K Y5P TP5 C111,C439 BA4102KG1H 2
212 E-C-0404-3649 1122946800 * CAP CD 100V 2.2KP K Y5P TP5 C109 BA5222KG1H 1
213 E-C-0404-3651 1132354800 CAP CD 500V .01U M Z5U TP5 C103,C122,C618 EC0103MG1H 3
214 E-C-0404-3652 1132930800 * CAP CD 500V 100P K Y5P TP5 C220,C450 BC4101KG1H 2
215 E-C-0404-3653 1132938800 * CAP CD 500V 220P K Y5P TP5 C203 BC4221KG1H 1
216 E-C-0404-3654 1132945800 * CAP CD 500V 1KP K Y5P TP5 C445 BC5102KG1H 1
217 E-C-0404-4673 1140030800 * CAP CD 1KV 100P J C0G TP5 C118 CHM0101JG1 1
208
E70f+SB-3 BOM
47
ViewSonic Corporation Confidential
-
Do Not Copy 70f+SB-3E
