Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
#N/A D503
E-D-0403-1937 204322000207 * DIO SW 0.25A 200V SOD-27(DO-35) D111,D112,D411,D412, BAV21,133 1
#N/A D423,D607,D609,D611,
#N/A D613,D614,D615
292 E-D-0403-1977 205012420137 DIO SI 5A 1500V/600V LF664(TO-220F D401 FMQ-2FUR 1
293 #N/A 205300550034 * DIO SI 1A 100V DO-41 D501 1N4002 T/B 1
294 E-D-0403-1690 205350610337 * DIO SI 1A 600V RG4 D203 RG 4A 1
295 E-Q-0402-1451 210013030006 * TR 60V 3A 2-10R1A 100-320 Q409 2SD2012 1
296 E-Q-0402-1452 210057920017 * TR 750V 12A TO-3PF 10 Q401 FJAF6812TU 1
297 E-Q-0402-1203 210101500111 * TR 30V 0.1A TO-92 160-320 Q212 2SC458CTZ 1
298 E-Q-0402-0906 210102500011 * TR 50V 0.5A TO-92 100-200 Q211 2SC1213ACTZ 1
E-Q-0402-1483 210102500217 * TR 50V 0.15A TO-92 200-400 Q103,Q104,Q201,Q204, KSC1815GRTA 5
#N/A Q207,Q210,Q405,Q407,
#N/A Q408,Q410,Q413,Q415,
#N/A Q417,Q421,Q423
230 E-Q-0402-1207 210105700006 * TR 250V 0.05A TO-92 50 Q501 BF422(TPE2) 1
231 E-Q-0402-1453 210106300017 * TR 350V 0.5A TO-92 30-200 Q102 2N6517TA 1
232 E-Q-0402-1454 210231010011 * TR 20V 1A TO-92MOD 120-240 Q206 2SD468CTZ 1
233 E-Q-0402-1206 210233510011 * TR 80V 1A TO-92MOD 100-200 Q402 2SD667CTZ 1
234 E-Q-0402-1479 211101500106 * TR -30V -0.5A TO-92 120-240 Q213 2SA562TM-Y(TPE2) 1
E-Q-0402-1455 211102500117 * TR -50V -0.15A TO-92 200-240 Q205,Q216,Q411,Q412, KSA1015GRTA 6
#N/A Q418,Q422
236 E-Q-0402-1208 211105700006 * TR -250V -0.05A 2-5F1B 50 Q419,Q420 BF423(TPE2) 2
237 E-Q-0402-0888 211106000106 * TR -300V -0.05A TO-92 40 Q404 BF421(TPE2) 1
238 E-Q-0402-1588 211162030006 * TR -40V -3A 2-8H1A 120-240 Q203,Q208 2SA1359-Y 2
239 E-D-0403-1199 2300062706 * LED 5mm ORG/GRN 3PIN LED301A EL339-1EGW 1
240 E-IC-0401-1873 2310040008 * PHOTO 55V 4PIN 100-300% VDE IC102 TLP721F(D4-GR) 1
241 E-Q-0402-1589 242016100517 * FET 200V 9A 0.4ohm TO-220F Q414,Q416 IRFS630B 2
242 E-Q-0402-1432 242016350517 * FET 250V 8.1A 0.45ohm TO-220F Q202 IRFS634B 1
243 E-Q-0402-0156 242017400006 * FET 600V 6A 1.25ohm TO-220F Q101 2SK2545 1
244 E-IC-0401-4004 2500165111 * IC 120V TRIPLE BIAS CLAMP DIP-8P IC603 LM2479NA 1
245 E-IC-0401-0985 2510005310 * IC PWM 8PIN IC101 UC3843BN 1
246 E-IC-0401-2730 2530026104 * IC VERT DEFLECTION SIP-10P IC501 KA2142 1
247 E-IC-0401-2275 2530095106 * IC DEFLECTION PROCESSOR SDIP-32P IC401 TDA9113 1
248 E-IC-0401-2393 2530159004 * IC RGB VIDEO PRE-AMP 24PIN IC601 LM1269 1
249 E-IC-0401-4003 2530159104 * IC WB AMP DRIVER RGB CRT TO-220-9P IC602 LM2460TA 1
250 E-IC-0401-2731 2530211226 IC MASK OSD CONTROLLER DIP-20P IC604 NT68295-90049 1
251 E-IC-0401-2852 2610185342 * IC EEPROM 8K 8PIN IC302 M24C08BN6 1
252 E-IC-0401-2762 2610561018 * IC 8BIT MICROCONTROLLER SDIP-42P F IC301 NT68F65U 1
253 E-T-0408-0323 2800421400 * X'FMR EE19 19mH K T402 19A-9008 1
254 #N/A 2831028200 BOBBIN+WIRE ASSY FOR 19A-9008 1
255 M-MS-0808-5087 3167921200 BOBBIN & LUG*5 ASSY 1
256 M-MS-0808-7460 3220311724 * TAPE W=10.5 CT-280 YAHUA CT-280 W=10.5 0.36
257 #N/A 4010400200 * WIRE CU 0.2 2UEW NAT 2.8
258 #N/A 4010560200 * WIRE CU 0.4 2UEW NAT 0.85
259 M-MS-0808-5168 4090001800 * SOLDER BAR 60/40 SB60 0.1
260 #N/A 3220310624 * TAPE W=5 CT-280 YAHUA CT-280 W=5 0.17
262 M-MS-0808-5145 4020116500 * EPOXY G757 0.005
263 M-MS-0808-5146 4020117500 * EPOXY 2089-1 A 2089-1 A 9.7
264 M-MS-0808-5147 4020117600 * EPOXY 2089-1 B 2089-1 B 0.097
265 M-MS-0808-5152 4020205500 THINNER OF V-1380 0.1
266 M-MS-0808-5153 4020208200 * FLUX ROSIN 800 NO CLEAN 800 NO CLEAN 0.001
267 M-MS-0808-5165 4020500500 * INK BLACK 0.001
268 M-MS-0808-5166 4020604000 * VARNISH V-1380FC VIKING V-1380FC 0.1
269 M-MS-0808-5168 4090001800 * SOLDER BAR 60/40 SB60 0.1
270 E-L-0407-1127 4120504700 * CORE FERI EE19 TP3 UI=2500 EE19 TP3 1
271 E-T-0408-0519 2801427200 * X'FMR SMT 250uH J T101 SMT-35RV-315T 1
272 #N/A 3166006000 * BOBBIN & LUG*12 L1=4.0+/-0.5 1
273 M-MS-0808-7466 3220311424 * TAPE W=9 CT-280 YAHUA CT-280 W=9 0.319
274 #N/A 3220316924 * TAPE W=26.5 CT-280 YAHUA CT-280 W=26.5 1.28
275 M-MS-0808-5095 3221202400 * TAPE W=5.6 3L #44 #44 W=5.6 3L 0.768
276 M-MS-0808-5096 3221202500 * TAPE W=2.8 3L #44 3M #44 W=2.8 3L 0.739
277 #N/A 4010460000 * WIRE CU 0.25 2UEW NAT 2.192
278 M-WR-0828-0426 4010580000 * WIRE CU 0.45 2UEW NAT 0.45# 2UEW NAT 2.24
279 #N/A 4011550400 * WIRE CU 0.35 2UEW NAT MW-75 2.811
280 M-MS-0808-5144 4020114600 * VARNISH V-1630FS VIKING CLEAR V-1630FS 0.1
281 M-MS-0808-5145 4020116500 * EPOXY G757 0.2
282 M-MS-0808-5146 4020117500 * EPOXY 2089-1 A 2089-1 A 0.1
283 M-MS-0808-5147 4020117600 * EPOXY 2089-1 B 2089-1 B 0.001
284 M-MS-0808-5153 4020208200 * FLUX ROSIN 800 NO CLEAN 800 NO CLEAN 0.1
285 M-MS-0808-5165 4020500500 * INK BLACK 0.08
286 M-MS-0808-5168 4090001800 * SOLDER BAR 60/40 SB60 0.1
287 #N/A 4131101500 * CORE FERI EER35L TP4 EER35L TP4 1
288 #N/A 2816381210 * CHOKE CD 100uH K L403 E-7691 1
289 E-L-0407-0710 2816800210 * CHOKE CD 3.9mH K L402 E-4840A 1
290 E-L-0407-0113 2816903700 * CHOKE CD 120uH K L201,L405 CD-16-087T 2
291 #N/A 3520462700 PML FOR DR18*22 1
292 #N/A 3500226300 * EPE PAD 265*230*8 0.003
299
235
290
291
E70f+SB-3 BOM
49
ViewSonic Corporation Confidential
-
Do Not Copy 70f+SB-3E
