Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
371 #N/A 4010170500 * WIRE CU 0.1#*30 2UEWN 2.2
372 M-MS-0808-5351 4020103000 * EPOXY TWO COMPONENT CLEAR C907 0.068
373 M-MS-0808-5352 4020200300 * SOLVENT XYLENE 0.058
374 M-MS-0808-5150 4020201200 * THINNER OF FLUX A83 ADDITIVE #425 0.016
375 M-MS-0808-5151 4020204800 FLUX A83 ALPHA A83 0.008
376 M-MS-0808-5357 4020600700 * VARNISH BC346 0.153
377 M-MS-0808-5167 4090001200 * SOLDER BAR 50/50 0.131
378 #N/A 4162170200 CORE FERI DR10*12 H471 B4 U750 1
379 E-L-0407-0020 2817601010 LINEAR COIL 6uH 0.1*3.0 L404 E-6005 1
380 E-FBT-0406-0237 2850008610 * FBT 17" 70KHZ 1.24mH T401 CF1803DE2700 1
E-L-0407-0494 2921020100 * CORE BEAD 3.5*6*1.0 T/R JW101,JW501,L103,L10 C8B RH3.5*6*1.0 T/R 8
#N/A 4,L105,L203,L611,L612
E-L-0407-1427 2921050700 * CORE BEAD 2.5*3*1.0 W5 T/R L202,L406,L409,L601, W5 RH2.5*3*1.0 T/R 8
#N/A L607,L608,L609,R611
383 E-L-0407-1497 2922100306 * COIL PEAKING .68UH K TP AXIAL 0307 L603,L604,L605,L610 CP-0307AT-R68K 4
384 E-L-0407-1243 2922130206 * COIL PEAKING 22uH K TP AXIAL 0307 L602,L606 CP-0307AT-220K 2
385 #N/A 2970038800 PWB S2 FR-1(XPC) 250*330 1
386 M-SW-0815-0176 3000091816 * SWITCH TACTILE DC 12V 50mA SW305 SKHHLM1510 5
387 M-SW-0815-0164 3000140426 * SWITCH PUSH SPST DC30V 0.3A 1
388 M-MS-0808-6069 3020005436 * SOCKET CRT NORMAL DOUBLE FOCUS SFCCB09120-TA 1
389 M-MS-0808-6790 3020603638 * SOCKET AC PWB MOUNT INPUT 10A 250V SA-4S-020 1
390 M-MS-0808-7802 3070023934 * HEADER NY66 94V0 7P P2.5 P301 A2501WV2-7P 1
391 M-MS-0808-7506 3071315634 * HEADER NY66 94V0 6PIN 1
392 M-MS-0808-5378 3071406334 * HEADER NY66 94V0 3P P2.5 P201 A2502WV2-3P 1
393 A-VC-0101-0344 3080421200 * CABLE D-SUB/HOUSING L1800 BLK OD6 1
394 M-SCW-0824-0391 3100300800 * SCREW M M3*0.5*8 PAN C S+P S20C ZN 1
395 M-SCW-0824-0004 3100301000 * SCREW M M3*0.5*10 PAN C S+P S20C Z 7
396 M-SCW-0824-0461 3106150400 * SCREW T M3.5*1*8 PAN C S18C ZN YEL 2
397 M-SCW-0824-0425 3106150600 * SCREW T M3*1*12 PAN C S18C ZN YEL 1
398 M-SCW-0824-0411 3109010300 * SCREW T M3*0.5*10 BIND C S18C ZN Y 1
399 M-SCW-0824-0413 3109011400 * SCREW T M3*0.5*6 BIND C S18C ZN YE 2
400 M-SCW-0824-0617 3109017300 * SCREW T M3*0.5*8 PAN C S S18C ZN 1
401 M-SCW-0824-0620 3109020500 * SCREW T ?p4*1.6*10 PAN C S18C ZN Y 1
402 M-SCW-0824-0393 3109020700 * SCREW T M4*0.7*8 PAN C S S18C ZN 1
403 M-MS-0808-7326 3110110400 * NUT M3*0.5 S1010C 7
404 M-LB-0813-0913 3202005900 * LABEL SERIAL 42*11 SONY 1
405 #N/A 3227000100 * TUBE HS POLYOLEFIN 7*.25 BLACK VERAFIT 7*2.5 BLK 0.015
406 M-MS-0808-5739 3227001900 * TUBE HS POLYOLEFIN 5*.25 BLACK VERSAFIT 5*0.25 BLK 0.02
407 M-MS-0808-7803 3240291900 INSULATOR SIRUB 12*26 T.275 1
408 #N/A 3340077500 HSK AL T=2.5 67*25*47 1
409 #N/A 3341061200 HSK AL T1.4 23.5*55.4 HS201 1
410 M-MS-0808-7327 3341714800 * HSK SPTH T=0.4 89*27*43.8 L 1
411 M-MS-0808-9678 3342602401 * HSK PLATE AL1100F PICKLING T1 187* 1
412 M-MS-0808-8237 3350141100 * RIVET BRASS TIN PLATED 1.8*3.7*3 2
413 M-MS-0808-5111 3350141900 * RIVET BRASS TIN PLATED 1.5*3.2*3 6
414 M-MS-0808-5112 3350143000 * RIVET BRASS TIN PLATED 1.2*3*3 1
415 M-MS-0808-5119 3350252200 * PIN ROUND BRONZE 2.36*13.8 TIN PLA GND3 5
416 M-MS-0808-4828 3360053201 * LED HOLDER NY66 NAT 1
417 M-WR-0828-0344 3411000200 * JUMP WIRE COPPER 0.6*5.0*4.0 JW104 1
418 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
M-WR-0828-0224 3411000300 * JUMP WIRE COPPER 0.6*7.5*4.0 J318,J420,JW108,JW20 2
#N/A 6
420 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
421 M-WR-0828-0249 3411000400 * JUMP WIRE COPPER 0.6*10.0*4.0 J210,JW110,R226 2
422 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
423 #N/A 3411000500 * JUMP WIRE COPPER 0.6*12.5*4.0 J446,R115,R401,R412 2
424 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
425 M-WR-0828-0388 3411000600 * JUMP WIRE COPPER 0.6*15.0*4.0 J308,J440 7
426 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
427 M-WR-0828-0389 3411000700 * JUMP WIRE COPPER 0.6*17.5*4.0 J410,J418 5
428 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
429 M-WR-0828-0390 3411000800 * JUMP WIRE COPPER 0.6*20.0*4.0 J312,J430 8
430 M-WR-0828-0402 4010670000 * WIRE CU 0.6 TNC 0.131
431 M-MS-0808-5008 3421030303 * CABLE TIE NYLON66 94V-2 YJ-98 1
432 M-MS-0808-6878 3423521802 * SHIELD CAN-VIDEO SPTH 90*90 T=0.3 1
433 M-MS-0808-5123 3429009300 * CLIP TIN SPTH 32*7 T=0.3 1
434 M-MS-0808-7487 3429019600 * CLIP TIN SPTH 30.5*7 T=0.3 1
435 M-MS-0808-7513 3460103202 * BRACKET REAR SECC 67*55 T=1 1
436 #N/A 3468200600 * CLIP FIXING SECC 30*10 T1.5 1
437 M-MS-0808-6945 3470401600 * SPACER SUPPORT ABS 94V0 20.5*10*14 1
438 M-WR-0828-0720 3641308202 * WIRE WITH TERMINAL 1007#18 BLK L15 1
439 M-WR-0828-5990 3642422902 * WIRE WITH TERMINAL 1015 #18 Y/G L9 1
440 M-WR-0828-0721 3670153800 * WIRE WITH HOUSING 1007 #24 L200 12 1
441 M-MS-0808-5153 4020208200 * FLUX ROSIN 800 NO CLEAN 800 NO CLEAN 9.5
442 M-MS-0808-5154 4020208300 * THINNER OF ROSIN 800 ADDITIV 800 ADDITIVE 1.36
443 M-MS-0808-5358 4090002400 * SOLDER BAR 63/37 5.4
444 #N/A X011002300 RES MF 1/4W 2.2K F SMALL R208 RN1/4S 2201 FTB 1
419
381
382
E70f+SB-3 BOM
51
ViewSonic Corporation Confidential
-
Do Not Copy 70f+SB-3E
