Item ViewSonic P/N Reference P/N Decription Qty
1 C-FP-0301-0958 3361088601 F/B ABS SILVER E71F+SB-3 S7PFB1AT 1
2 PL-NB-0707-0196 3360625100 POWER KNOB ABS 41 S7PFB1AT 1
3 M-MS-0808-7805 3360506500 LED LENS PMMA NAT Y0-487 S7FB2AT 1
4 M-MS-0808-7806 3462003900 SPRING COMPRESSION SUS304 ID6.5 L12 1
5 PL-FK-0709-0120 3360728400 FUNCTION KEY ABS 41 S7PFB1AT 1
6 M-LB-0813-0466 3209135100 NAME PLATE AL+PC VSC 3-BIRD LOGO 24.7* 1
7 PL-PD-0714-0021 3240920800 RUBBER PAD 20*6.5*5 BLACK 4
8 M-WR-0828-6643 3649109801 CRT GROUNDING WIRE J770SBM 1
9 E-L-0407-1493 2840003906 DEGAUSSING COIL 14.4 OHM K 1
10 B-VB-0202-0360 PART# UNKNOWN VIDEO BOARD ASS'Y 1
11 M-MS-0808-6878 3423521802 SHIELD CAN-VIDEO SPTH 90*90 T=0.3 1
12 C-BC-0302-0614 3360242301 R/C ABS 41 S7RB1AT 1
13a M-LB-0813-0988 3201970600 LABEL ID 65*75 E70F+ J770SBM06C( CHINA ) 1
13b M-LB-0813-0989 3201968900 LABEL ID 65*75 E70F+ J770SBM06C( USA ) 1
13c M-LB-0813-1026 3201966900 LABEL ID 65*75 E70F+ J770SBM06C( EU ) 1
13d M-LB-0813-1027 3201971000 LABEL ID 65*75 E70F+ J770SBM06C( AUS ) 1
13e M-LB-0813-0925 3201969100 LABEL ID 65*75 E70F+ J770SBM06C( ASIA ) 1
14 M-SCW-0824-0394 3109022200 SCREW T p4*1.6*35 PAN C S18C ZN 2
15 M-SCW-0824-0006 3109020201 SCREW T p4*1.4*16 PAN C S18C ZN YEL 2
16 C-BS-0303-0541 3360318700 SWIVEL ABS EP32 S7SB1EL 1
17 C-BS-0303-0397 3360425000 BASE ABS 41 S7SB1EL 1
18 M-SW-0815-0176 3000091816 SWITCH TACTILE DC 12V 50mA 4
19 M-MS-0808-9199 2300062706+3360053201 LED+HOLDER 1
20 M-SW-0815-0164 3000140426 SWITCH PUSH SPST DC30V 0.3A 1
21 B-MB-0201-0753 5600010522 PCB ASS'Y 1
22 M-MS-0808-4206 3421047903 SPACER SUPPORT NYLON 94V-2 14*9*11.8 2
23 M-MS-0808-6945 3470401600 SPACER SUPPORT ABS 94V0 20.5*10*14.45 1
24 M-MS-0808-9678 3342602401 HSK PLATE AL1100F PICKLING T1 187*60*9 1
25 M-MS-0808-7513 3460103202 BRACKET REAR SECC 67*55 T=1 1
26 M-MS-0808-6790 3020603638 SOCKET AC PWB MOUNT INPUT 10A 250V 1
27 A-VC-0101-0344 3080421200 CABLE D-SUB/HOUSING L1800 BLK OD6 1
28 M-SCW-0824-0393 3109020700 SCREW T M4*0.7*8 PAN C S S18C ZN 1
29 M-SCW-0824-0413 3109011400 SCREW T M3*0.5*6 BIND C S18C ZN YEL 1
30 M-SCW-0824-6767 3100301000+3110110400 SCREW+NUT 1
31 M-SCW-0824-0617 3109017300 SCREW T M3*0.5*8 PAN C S S18C ZN 1
32 M-MS-0808-7803 3240291900 INSULATOR SIRUB 12*26 T.275 1
33 M-SCW-0824-0413 3109011400 SCREW T M3*0.5*6 BIND C S18C ZN YEL 1
34 M-SCW-0824-0393 3109020700 SCREW T M4*0.7*8 PAN C S S18C ZN 1
35 E-CRT-0409-0468 0741708210 CRT .25 17" 90D FLAT TCO 184uH 1
E70f+SB-3 Exploded Part List
53
ViewSonic Corporation Confidential
-
Do Not Copy 70f+SB-3E
