- 32 –
ViewSonic Corporation
Confidential - Do Not Cop VA1721wmb
2.5 Connect P3 to the Signal Generator (eg.Chroma2326) for verifying it after the
operation being completed.
2.6 Connect PC to the additional monitor.
3 Firmware Upgrade Procedure
Step 1. Let Monitor(TSUM series) set to be connected with AC cable and VGA cable.
Step 2.Execute the MSstar ISP tool.
P2：to LPT Cable
JP1
To Next Page
