ViewSonic Corporation Confidential - Do Not Copy VA1912w-3_VA1912wb-3
2.5 ELECTRICAL REQUIREMENT
Horizontal / Vertical Frequency
Horizontal Frequency
30 – 82 kHz
Vertical Refresh Rate
50 – 85* Hz.
Maximum Pixel Clock 135 MHz (EDID file is 140MHz)
Sync Polarity Independent of sync polarity.
Timing Table
Item Timing Analog Digital
1 640 x 350 @ 70Hz, 31.5kHz Yes Yes
2 640 x 400 @ 60Hz, 31.5kHz Yes* Yes
3 640 x 400 @ 70Hz, 31.5kHz Yes Yes
4 640 x 480 @ 60Hz, 31.5kHz Yes Yes
5 640 x 480 @ 67Hz, 35.0kHz Yes Yes
6 640 x 480 @ 72Hz, 37.9kHz Yes Yes
7 640 x 480 @ 75Hz, 37.5kHz Yes Yes
8 640 x 480 @ 85Hz, 43.27kHz Yes Yes
9 720 x 400 @ 70Hz, 31.5kHz Yes Yes
10 800 x 600 @ 56Hz, 35.1kHz Yes Yes
11 800 x 600 @ 60Hz, 37.9kHz Yes Yes
12 800 x 600 @ 75Hz, 46.9kHz Yes Yes
13 800 x 600 @ 72Hz, 48.1kHz Yes Yes
14 800 x 600 @ 85Hz, 53.7kHz Yes Yes
15 832 x 624 @ 75Hz, 49.7kHz Yes Yes
16 1024 x 768 @ 60Hz, 48.4kHz Yes Yes
17 1024 x 768 @ 70Hz, 56.5kHz Yes Yes
18 1024 x 768 @ 72Hz, 58.1kHz Yes Yes
19 1024 x 768 @ 75Hz, 60.0kHz Yes Yes
20 1024 x 768 @ 85Hz, 68.67kHz Yes Yes
21 1152 x 864@ 75Hz, 67.5kHz Yes Yes
22 1280 x 1024 @ 60Hz, 63.4kHz Yes Yes
23 1280 x 1024 @ 75Hz, 79.97kHz Yes No
24 1280x 768 @ 60Hz, 47.78kHz Yes Yes
25 1280 x 960 @60Hz, 60kHz Yes Yes
26 1440 x 900 @ 60Hz, 55.96kHz Yes Yes
*The image vertical size might not be full screen.
