ViewSonic VA1912w-3 - Recommended Spare Parts List

45
ViewSonic Corporation Confidential - Do Not Copy VA1912w-3_VA1912wb-3
7. Recommended Spare Parts List
ViewSonic Model Number: VS10866
Serial No. Prefix: QBK Rev: 1a
Item Description ECR/ECN ViewSonic P/N Ref. P/N Location Universal number# Q'ty
1
Accessories:
Power Code, UL, SVT#18/3C, 75C, LP-30B+LS-13, L=1830+/-50mm, Black,
Linetek, 18AWG, No Bag, Green I
A-00008008 32E1818015
(AJ0A2H6A25)
1
2
PCBA for , A190A2-H, A190A2-H-K3, 106-02, Rev.02, USI/ITC, ODM, Green II B-00005600 35-D005166
1
3
PCBA for , A190A2-A02-T, A190A2-A02-H-S1, 1206-04, Rev.04, ODM, Green II B-00005705 35-D005062
1
4
Power Supply Board (Lips With Audio)DAC-12M030 A, Ver:0F, 5 V/3 A, 12 V/0.7
A, I TYPE, 7 mA, 1710 V, Delta Dongguan_Inverter/Delta Jiangsu_Adaptor, RoHS
B-00008008 27-D007836
1
5
Bezel Assy, A190A2-H05, ABS PA757N, Silver(Pantone877C), Fuking C-00004281 40-D004255 1
6
Rear Assy, A190A2-H05, ABS PA757N, Black(J91A11B5), Fuking C-00004282 40-D004257 1
7
Cover Hinge, A190A2-H05, ABS PA757N, Black(J91A11B5), Fuking C-00004284 40-D004250 1
8
Seat Assy, A190A2-H05, ABS PA757N, Black(J91A11B5), Hontech Precision C-00004285 40-D004259 1
9
Audio Cable, A150X2, 18AWG, 180cm, Black, JCE, Green I CB-00000544 32F2818004 1
10
Accessory Cable, D-Sub, BLACK, Johnson Components & Equipments, A150X2,
Green I
CB-00004287 32F3018003
1
11
FFC, A190A2-H05, 15 Pins, Tennsure/Young Shin, L=108.5 CB-00004288 32-D004533 1
12
FFC, FFCX816, 36 Pins, Tennsure, package AL_Foil, Green II CB-00005742 32-D005773 1
13
Safety Label for , A190A2-H05, 120 mmx50 mm, Chang Huang, VSC_VA1912w-2,
Green II
DC-00008009 77-D012196
1
14
Label, Pallet Barcode Label, 75x40, A190E2-H03, VSC, Non Green DC-00008010 7741513161 1
15
Carton Label for , A190E2-H06, 20 mmx20 mm, Chang Huang, VSC_VA912_for
Europe, Green I
DC-00008011 77-D011736
1
16
MENU for A190A2-H05, Complex, 1C, VSC_VA1912w/wb-3 +Caution Card,
Green II
DC-00008012 76-D011749
1
17
SCREW, M3, P=0.5 mm, L=4 mm, Pan Head, Phillips Cross Recess, Green I HW-00000553 42A9930008 2000
18
Screw, M3*P1.27*12, φ5.5*2, Steel, Green I HW-00000556 42A9990005 2000
19
SCREW, M4, P=0.7 mm, L=15 mm, Pan Head, Phillips Cross Recess, Green I HW-00000590 42A9930013 2000
20
SCREW, M4, P=0.7 mm, L=8 mm, Round Head, Phillips Cross Recess, plate color
Zn, Screw_with_Washer, Shye Ching/Hama Naka Motogawa, head D8, Green I
HW-00004042 42-D000649
2000
21
SCREW, M4, P=0 mm, L=11.8 mm, Hexagon Stand Off, Socket, Green I HW-00006041 42A9940007 2000
22 Miscellaneous:
Tape, Security Tape, OPP, L900xW50x0.045mm, VSC, Non Green M-00000560 7345511002 1
23
Bag, 570 mmx600 mmx0.13 mm, White, Non Green P-00000595 7841919921 1
24
Cushion, A190A2-T05, EPS, WHITE, 450 mmx160 mmx145 mm, Sing Home, PS
FOAM (Left), Green II
P-00004295 78-D004392
1
25
Carton, A190A2-H05, , 538 mmx158 mmx470 mm, VSC_VA1912w-3 5ms, Green
II
P-00008012 78-D011686
1
26
Cushion, A190A2-T05, EPS, WHITE, 450 mmx160 mmx145 mm, Sing Home, PS
FOAM (Right), Green II
P-00004296 78-D004388
1
Remark 1:
Remark 2: All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation. This is to eliminate repeated
cross checks of each item between this version and prior versions.
Above listed items are examples, supplier can expand the rows to add more necessary items.
Hardware:
RECOMMENDED SPARE PARTS LIST (VA1912W-3)
Packing Material:
PC Board Assembly:
Cabinets:
Cables:
Documentation:
