ViewSonic VA1912w-3 - Page 49

ViewSonic Model Number: VS1086
6
Serial No. Prefix: QBN Rev: 1a
Item Description ECR/ECN ViewSonic P/N Ref. P/N Location Universal number# Q'ty
1
Accessories:
Power Cord, PC-323+COC-01, Black, CCC, 1830 mm, Green I A-00002058 32E1818013
1
2
PCBA for , A190A2-H, A190A2-H-K3, 106-02, Rev.02, USI/ITC,
ODM, Green I
B-00005600 35-D005166
1
3
Lips With Audio, DAC-19M008 AF, 0F, 5 V/3 A, 13.8 V0.7 A, I
TYPE, 7 mA, 1710 V, , Green II
B-00008008 27-D007836
1
4
Audio Control PCBA for , A190A2-A02-H, A190A2-A02-H-S1, 1206-
05, Rev.04, IGreen II
B-00008011 35-D008184
1
5
Bezel Assy, A190A2-H05, ABS PA757N, Green
I
C-00004276 40-D004254
1
6
Rear Assy, A190A2-H05, ABS PA757N, Green
I
C-00004277 40-D004253
1
7
Cover Hinge, A190A2-H05, ABS PA757N, Green
I
C-00004279 40-D004258
1
8
Seat Assy, A190A2-H05, ABS PA757N, Green
I
C-00004280 40-D004256
1
9
Audio Cable, A150X2, 18AWG, 180cm, Black, JCE, Green
I
CB-00000544 32F2818004
1
10
Accessory Cable, D-Sub, BLACK, Johnson Components & Equipments,
A150X2, Green I
CB-00004287 32F3018003
1
11
FFC, A190A2-H05, 15 Pins, Tennsure/Young Shin, L=108.
5
CB-00004288 32-D004533
1
12
FFC, FFCX816, 36 Pins, Tennsure, package AL_Foil, Green I
I
CB-00005742 32-D005773
1
13
Safety Label for , A190A2-H05, 120 mmx50 mm, VA1912wb Ver.3,
Green II
DC-00008016 77-D012194
1
14
SN Label for , A190A2-H05, 50 mmx25 mm, VA1912wb-3 for China,
Green II
DC-00008017 77-D011742
1
15
Carton Label for , A190A2-H05, 76.2 mmx76.2 mm, VA1912wb-3,
Green II
DC-00008018 77-D011733
1
16
MENU for A190A2-H05, VA1912w/wb-3, Green II DC-00008019 76-D011751
1
17
SCREW, M3, P=0.5 mm, L=4 mm, Pan Head, Phillips Cross Recess,
Green I
HW-00000553 42A9930008
2000
18
Screw, M3*P1.27*12, φ5.5*2, Steel, Green I HW-00000556 42A9990005
2000
19
SCREW, M4, P=0.7 mm, L=15 mm, Pan Head, Phillips Cross Recess,
Green I
HW-00000590 42A9930013
2000
20
SCREW, M4, P=0.7 mm, L=8 mm, Round Head, Phillips Cross Recess,
plate color Zn, Screw_with_Washer, Shye Ching/Hama Naka Motogawa,
head D8, Green I
HW-00004042 42-D000649
2000
21
SCREW, M4, P=0 mm, L=11.8 mm, Hexagon Stand Off, Socket,
Green I
HW-00006041 42A9940007
2000
22
Miscellaneous:
Tape, Security Tape, OPP, L900xW50x0.045mm, VSC, Non Gree
n
M-00000560 7345511002
1
23
Bag, 570 mmx600 mmx0.13 mm, White, Non Gree
n
P-00000595 7841919921
1
24
Cushion, A190A2-T05, EPS, WHITE, 450 mmx160 mmx145 mm, Sing
Home, PS FOAM (Left), Green II
P-00004295 78-D004392
1
25
Cushion, A190A2-T05, EPS, WHITE, 450 mmx160 mmx145 mm, Sing
Home, PS FOAM (Right), Green II
P-00004296 78-D004388
1
26
Generic Foam Se
t
P-00001347 30833
27
Generic Bo
x
P-00002515 20653
28
Craft Box, A190A2-H05, 538 mmx158 mmx470 mm, VA1912wb-3 5ms,
Green II
P-00008014 78-D011685
1
Remark 1:
Remark 2:
Above listed items are examples, supplier can expand the rows to add more necessary items.
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR
approved by ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior
RECOMMENDED SPARE PARTS LIST (VA1912WB-3)
PC Board Assembly:
Cabinets:
Cables:
Documentation:
Hardware:
Packing Material:
46
ViewSonic Corporation Confidential - Do Not Copy VA1912w-3_VA1912wb-3
