ViewSonic Model Number: VS10866
Rev: 1a
Serial No. Prefix: QBK
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 N/A MJ0A10DK01
Olympic, 19" Wide, Common BOM(Semi-Product), A190A2, 1440X900, TN,
5ms
1
2 N/A 36X8636401 Driver IC, Scan, 300Channel, , RoHS, Green I 3
3 N/A L3J009XXX8 19" wide PS TN Asahi 0.7mm glass Resin BM (Panel Base) 1
4 N/A 74-D002212
Polarizer, TFT, Degree 135, 414 mmx259.7 mmx0.215 mm, NWF-LESEG,
M190A1, Green I
1
5 N/A 74-D002213
Polarizer, CF, Degree 135, 415.84 mmx262.15 mmx0.215 mm, NWF-
LESEGAGS1, M190A1, Green I
1
6 N/A 73-C000047
ACF, COG, AC-8405Z-23 1.5mmX100M, 100000 mmx1.5 mm, COG-ACF,
Green I
0.00168
7 N/A 7344191017 ACF, AC-4251FY-16, 100M/RL, Green I 0.0044
8 N/A 36-D002378
Driver IC, COF, Data, M190A1-L01, HX8018-A050CBAK, Reel, 6 bit,
432Channel, RoHS, Green I
10
9 N/A 73-D002676 ACF, PCB, AC-9825R-35, 100000 mmx1.5 mm, PCB-ACF, Green I 0.0044
10 N/A 35-D004361 PCBA for , A190A2-H, A190A2-A02-H-X, 1206-01, Rev.01, Green I 1
11 N/A 7349951002 Silicone, TORAY/-9187L, 330g 0.4
12 HW-00000553 42A9930008
SCREW, M3, P=0.5 mm, L=4 mm, Pan Head, Phillips Cross Recess, Green I
16
13 HW-00006041 42A9940007 SCREW, M4, P=0 mm, L=11.8 mm, Hexagon Stand Off, Socket, Green I 2
14 N/A 41-D000643
Metal Frame Front, M190A1-L01/A190A2/M190A1-L03, SECC 0.6t, 19"wide
1
15 HW-00004042 42-D000649
SCREW, M4, P=0.7 mm, L=8 mm, Round Head, Phillips Cross Recess, plate
color Zn, Screw_with_Washer, head D8, Green I
1
16 N/A 73-D002886
Conductive Tape, PET+Adhesive, 409 mmx58.55 mmx0.05 mm,
Mylar_Cover_PcbaX_a190a2, Green I
1
17 B-00006039 27-D003247
Lips With Audio, DAC-12M030 A, Ver:0F, 5 V/3 A, 12 V/0.7 A, I TYPE, 7
mA, 1710 V, RoHS
1
18 N/A 44-D003584 Backlight Unit, A190A2, Green I 1
19 C-00005686 41-D003772 Cover AD Assy, A190A2, SECC, without Dvi-D Hole, Green II 1
20 N/A 35-D008184 PCBA for , A190A2-A02-H, A190A2-A02-H-S1 1
21 CB-00005742 32-D005773 FFC, FFCX816, 36 Pins, package AL_Foil, Green II 2
22 N/A PJ0EACL000
Accessory BOM, D-sub+DVI+Audio, China 3 pin, Black, Power built-in;RoHS
1
23 CB-00002083 32F0000004 Accessory Cable, DVI, Black
24 CB-00000544 32F2818004 Audio Cable, A150X2, 18AWG, 180cm, Black, JCE, Green I 1
25 CB-00004287 32F3018003 Accessory Cable, D-Sub, BLACK, A150X2, Green I 1
26 A-00002058 32E1818013
Power Cord, CCC, 300/500V, 0.75mm2, 3C, PC-323+COC-01, L=1830+/-
50mm, Black, Linetek, 18AWG, No Bag, Green I
1
27 HW-00000590 42A9930013 SCREW, M4, P=0.7 mm, L=15 mm, Pan Head, Green I 4
28 HW-00000555 42A9930014 Screw, M3*P0.5*6, Green I 4
29 HW-00000556 42A9990005 Screw, M3*P1.27*12, φ5.5*2, Steel, Green I 2
30 C-00004284 40-D004250 Cover Hinge, A190A2-H05, ABS PA757N, Black(J91A11B5) 1
31 C-00004282 40-D004257 Rear Assy, A190A2-H05, ABS PA757N, Black(J91A11B5) 1
32 C-00004281 40-D004255 Bezel Assy, A190A2-H05, ABS PA757N, Silver(Pantone877C) 1
33 CB-00004288 32-D004533 FFC, A190A2-H05, 15 Pins, L=108.5 1
34 B-00005600 35-D005166 PCBA for , A190A2-H, A190A2-H-K3, 106-02, Rev.02, ODM, Green II 1
35 C-00004283 40-D004252 Stand Assy, A190A2-H05, ABS PA757N, Black(J91A11B5) 1
36 PL-00006048 73-D005900
Panel Protector Film, A190A2-H05, XG-536 T=0.1, With_Print, Green II
1
37 DC-00005602 77-D008324
Safety Label for , A190A2-H05, 120 mmx50 mm, VSC_VA1912w-2, Green II
1
38 N/A 77-D008330
SN Label for , A190A2-H05, 50 mmx25 mm, VSC_VA1912w-2 for China,
Green II
1
39 HW-00002076 7841595111 Corner Protector, paper, 50 mmx50 mmx1850 mm, Green I 1
40 N/A 7841595191 Separator, 紙板(AA), 1120*820*11mm, A150X2-T01, Non Green 0.025
41 P-00000595 7841919921 Bag, 570 mmx600 mmx0.13 mm, White, Non Green 1
42 DC-00000586 7741999141 Label, Pallet Barcode Label, 75x40, A190E2-H03, VSC, Non Green 0.021
43 M-00000560 7345511002 Tape, Security Tape, OPP, L900xW50x0.045mm, VSC, Non Green 0.3
44 N/A 77-D000114 Customer Label, A170E1-H0G, 180 mm, 100 mm, Green I 1
45 N/A 77-D000118 Customer Label, A170E1-H0G, 130 mm, 80 mm, Green I 1
46 N/A 78-D000275 Warranty Card, A170E1-H0G, 143 mmx210 mm, VSC_VA712, Green I 1
47 DC-00005603 77-D000576
Carton Label for , A190E2-H06, 20 mmx20 mm, VSC_VA912_for Europe,
Green I
1
48 N/A 77-D001323
Customer Label for , A170E1-H0G, 15 mmx15 mm, QC Pass Label_VSC_for
China, Green I
1
49 N/A 78-D001492 Pallet, A150X2-T01, Wooden, 1150 mmx840 mmx138 mm, Green I 0.02
50 C-00004285 40-D004259 Seat Assy, A190A2-H05, ABS PA757N, Black(J91A11B5) 1
51 P-00004295 78-D004392
Cushion, A190A2-T05, EPS, WHITE, 450 mmx160 mmx145 mm, PS FOAM
(Left), Green II
1
52 P-00004296 78-D004388
Cushion, A190A2-T05, EPS, WHITE, 450 mmx160 mmx145 mm, PS FOAM
(Right), Green II
1
53 N/A 79-D004425 Shipping Package Information for , A190A2-H05, ViewSonic 1
54 N/A 77-D000114 Customer Label for , A170E1-H0G 1
55 N/A 78-D011686 Carton, A190A2-H05 1
56 N/A 76-D011751 MENU for A190A2-H05 1
BOM LIST (VA1912W-3)
47
ViewSonic Corporation Confidential - Do Not Copy VA1912w-3_VA1912wb-3
