Timing Table
Analog
Item Timing
Separated
Composite
SOG
Digital - TMDS
Remark
1 640 x 350 @ 70 Hz, 31.5 KHz DMT
2 640 x 400 @ 60 Hz, 31.5 KHz
3 640 x 400 @ 70 Hz, 31.5 KHz
4 640 x 480 @ 50 Hz, 24.7 KHz
5 640 x 480 @ 60 Hz, 31.5 KHz DMT
6 640 x 480 @ 67 Hz, 35 KHz For MAC
7 640 x 480 @ 72 Hz, 37.9 KHz DMT
8 640 x 480 @ 75 Hz, 37.5 KHz DMT
9 720 x 400 @ 70 Hz, 31.5 KHz
10 720 x 480 @ 60 Hz, 31.5 KHz DTV
11 720 x 576 @ 50 Hz, 31.3 KHz DTV
12 800 x 600 @ 56 Hz, 35.1 KHz DMT
13 800 x 600 @ 60 Hz, 37.9 KHz DMT
14 800 x 600 @ 72 Hz, 48.1 KHz DMT
15 800 x 600 @ 75 Hz, 46.9 KHz DMT
16 832 x 624 @ 75 Hz, 49.7 KHz MAC
17 1024 x 768 @ 50 Hz, 39.6 KHz
18 1024 x 768 @ 60 Hz, 48.4 KHz DMT
19 1024 x 768 @ 70 Hz, 56.5 KHz DMT
20 1024 x 768 @ 72 Hz, 58.1 KHz
21 1024 x 768 @ 75 Hz, 60 KHz DMT
22 1024 x 768 @ 75 Hz, 60.2 KHz For MAC
23 1152 x 864 @ 75 Hz, 67.5 KHz DMT
24 1152 x 870 @ 75 Hz, 68.7 KHz For MAC
25 1152 x 900 @ 67 Hz, 62.5 KHz For SUN
26 1280 x 720 @ 50 Hz, 37.5 KHz DTV
27 1280 x 720 @ 60 Hz, 45 KHz DTV
28 1280 x 768 @ 50 Hz, 39.6 KHz
29 1280 x 768 @ 60 Hz, 47.8 KHz DMT;
30 1280 x 768 @ 75 Hz, 60.3 KHz DMT;
31 1280 x 960 @ 50 Hz, 49.4 KHz
32 1280 x 960 @ 60 Hz, 59.7 KHz DMT
33 1280 x 960 @ 75 Hz, 75.2 KHz
34 1280 x 1024 @ 50 Hz, 52.7 KHz
35 1280 x 1024 @ 60 Hz, 64 KHz DMT
36 1280 x 1024 @ 75 Hz, 80 KHz DMT
37 1440 x 900 @ 60 Hz 59.9 KHz DMT
Primary Presets
1440x900 @ 60Hz
User Presets
Number of User Presets (recognized timings) Available: 10 presets total in FIFO configuration
Changing Modes
z Maximum Mode Change Blank Time for image stability: 3 seconds (Max), excluding “Auto Image Adjust” time.
z Under DOS mode (640 x 350, 720 x 400 & 640 x 400), it should recall factory setting when execute “Auto
Image Adjust”.
The monitor needs to do “Auto Image Adjust” the first time when a new mode is detected. (See section “0-Touch™
Function Actions”)
