ViewSonic Corporation Confidential - Do Not Copy VA1930wm-1
27
77 LVB0P O B-Link Positive LVDS Differential Data Output
78 LVB0M O B-Link Negative LVDS Differential Data Output
79 GND Ground
80 BYPASS For External Bypass Capacitor
81 NC Not connected
82 VDDC I Digital Core Power
83 GND Ground
84 RST I Chip Reset; High Reset
85 GPIO_P12 I/O General Purpose Input/Output; 4mA driving strength
86 PWM1/GPIO_P25 I/O
Pulse Width Modulation Output; 4mA driving
strength/General Purpose Input/Output; 4mA driving
87 RSTN I Chip Reset; Low Reset
88 GPIO_P00/SAR1 I/O
General Purpose Input/Output; 4mA driving
strength/SAR ADC Input
89 GPIO_P01/SAR2 I/O
General Purpose Input/Output; 4mA driving
strength/SAR ADC Input
90 GPIO_P02/SAR3 I/O
General Purpose Input/Output; 4mA driving
strength/SAR ADC Input
91 GPIO_P06 I/O
General Purpose Input/Output; 6/12mA
programmable driving strength
92 GPIO_P07 I/O
General Purpose Input/Output; 6/12mA
programmable driving strength
93 PWM0/GPIO_P26 I/O
Pulse Width Modulation Output; 4mA driving
strength/General Purpose Input/Output; 4mA driving
strength
94 GPIO_P13 I/O General Purpose Input/Output; 4mA driving strength
95 GPIO_P14 I/O General Purpose Input/Output; 4mA driving strength
96 XIN I Crystal Oscillator Input
97 XOUT O Crystal Oscillator Output
98 AVDD_MPLL I MPLL Power
99 GPIO_P16/PWM2 I/O
General Purpose Input/Output; 4mA driving strength/
Pulse Width Modulation Output; 4mA driving strength
100 NC Not connected
