ViewSonic VA1930wm-1 User Manual

ViewSonic Model Number: VS11354
Rev: 1a
Serial No. Prefix: QFP
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 P-00008167 506040009710R CUSHION,EPS-R, LE1945 100
2 P-00008168 506040009700R CUSHION,EPS-L, LE1945 100
3 N/A 506039000100R CORNER PAPER,1000x50x50xT5mm 5.556
4 N/A 506037005900R CARDBOARD,COVER,L1160xW1150xH120mm,LE194 2.778
5 CB-00008002 453030300120R CABLE,AUDIO 1P 6FT BLACK/GREEN CP03B06P0 100
6 A-00006679 453070800250R PWR CORD 10A/125V BLK 6FT UL/CSA,SVT 18x 100
7 CB-00008009 453010100150R CABLE,D-SUB 15P MALE 6FT BLACK,SZ4120955 100
8 N/A 506431000300R FILM,PE 500mmx900M ROHS 0.25
9 N/A 506431003100R FILM,PROTECTION,UNPRINTED,430x280x0.1mm, 100
10 N/A 506440002300R LABEL,BLANK,76.2x76.2mm,LE1709(UPC) 100
11 N/A 506440002400R LABEL,BLANK,50x25mm,LE1709(S/N) 100
12 N/A 506250012200R LABEL,AGENCY,LE1945(VA1930wm) 100
13 N/A 506390000600R LABEL,HI-POT PASS, LE1709 100
14 N/A 506390500100R LABEL,ENERGY STAR, LE1709 100
15 N/A 506390210400R LABEL,CARTON(5ms),L89xW58 LE1941 100
16 N/A 506440002600R LABEL,BLANK,210x65mm,LE1709(PALLET) 6.25
17 N/A 506391000030R LABEL,POP,FOR BEZEL, LE1945 100
18 N/A 506520700100R FLYER,LCDTV,LE1945(VA1930wm) 100
19 P-00008169 506020012310R CARTON,VIEWSONIC(VA1930wm), LE1945 100
20 P-00008170 506120301700R BAG,EPE+PE,L620xW510xT0.6mm, LE1925 100
21 N/A 506150007200R PALLET,L1140xW1130xH120mm,LE1945 1.389
22 N/A 506039003600R CORNER PAPER,1980x50x50xT5mm, LP1701 5.556
23 A-00008063 703000003910R KIT,ACCESSORY,LE1945(VA1930wm) 100
24 N/A 714078061101R ASSY,FINAL(B,V0/G1&2&3),W/SPK,US,LE1945- 100
25 N/A 501030204400R BUTTON,FUNCTION KEY, LE1941 100
26 N/A 501060200500R HOLDER,KEY PAD, LE1941 100
27 C-00008182 501020209600R COVER,HINGE(B), LE1945 100
28 N/A 509116608100R SCREW,P,CROSS,M4*8,Zn,ROHS 400
29 N/A 509112306100R SCREW,P,CROSS,T.T-3*6,ZnROHS 500
30 N/A 503040000310R RUBBER,COVER(B), LE1534 400
31 E-00008012 618100101500R SPEAKER 1.5W 16Ω 350mm,R/B,W/CASE,X3516 100
32 N/A 509112306100R SCREW,P,CROSS,T.T-3*6,ZnROHS 500
33 C-00008180 714050007400R ASSY,BACK COVER, LE1945 100
34 N/A 506430300003R FILM,PET,L115xW30xT0.05mm, LE1741 100
35 N/A 501020209400R COVER,BACK(B),W/DVI, LE1941 100
36 C-00008181 714030007410R ASSY,BEZEL, ,NO SILKSCREEN LE1945 100
37 N/A 501010207710R BEZEL,FRONT,NO SILKSCREEN,LE1945 100
38 N/A 501030204300R BUTTON,POWER KEY, LE1941 100
39 N/A 506102000400R LOGO PLATE,VIEWSONIC, LE1709(THREE BIRDS 100
40 N/A 506102000300R LOGO PLATE,VIEWSONIC, LE1709 100
41 N/A 501120104400R LENS, LE1941 100
42 PL-00008045 714010008600R ASSY,STAND LE1945 100
43 N/A 714088061100R ASSY,PANEL(V0/G1&2),W/SPK,LE1945-642 100
44 N/A 502090304100R CHASSIS,W/DVI, LE1941 100
45 HW-00005269 509146305300R SCREW,PW,CROSS,W/WAS,M3*5,NI 600
46 HW-00005270 509000000700R BOLT,#4-40x11.8,Ni FOR D-SUB/DVI CONN.RO 400
47 N/A 506380001200R TAPE,MYLAR,66000x20xT0.05 0.12
48 B-00008165 790691302600R PCBA,I/F BOARD, LE1945-642 100
49 B-00008023 790691401600R PCBA,P/I BOARD, LE1941-642 100
50 B-00008025 790682201000R PCBA,LED BOARD, LE1941 100
51 B-00008024 790691501000R PCBA,KEYPAD BOARD, LE1941 100
52 E-00008016 631102090600R LCD PANEL 19" MT190AW01-V0-G1,AM19000040 100
53 N/A 631102090610R LCD PANEL 19" MT190AW01-V0-G3,AM19000040 0
54 N/A 631102090720R LCD PANEL 19" MT190AW01-V0-G2,AM19000040 0
55 CB-00008010 430300400110R HRN ASS'Y 4P 240mm UL1571#28,RoHS 100
56 CB-00008013 430303000600R HRN LVDS FFC 30P 160mm,RoHS 100
57 CB-00008011 430300800710R HRN ASS'Y 4Px2 to 8P,270mm UL1571#28,RoH 100
58 N/A 505040503400R INSULATOR,PP,10x15x10X0.3mm,GLUE(3M), LE 400
59 N/A 509146304100R SCREW,P,CROSS W/WAS,M3*4,Zn ROHS 400
60 N/A 505040204000R INSULATOR,MYLAR,L370xW6xT0.3mm,LE1909 250
BOM LIST (VA1930wm-1)
ViewSonic Corporation Confidential - Do Not Copy VA1930wm-1
48
