7. Recommended Spare Parts List
ViewSonic Model Number: VS10866
Serial No. Prefix: QCB Rev: 1a
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number# Q'ty
1
Accessories:
Power Cord A-00002058 32E1818013 1
2 Audio Board (Rev.02) B-00005600 35-D005166 1
3 Audio Control Board (Rev.04) B-00005705 35-D005062 1
4 Power Supply Board (Ver:0F)Lips with Audio B-00008008 27-D007836 1
5
Cabinets:
Cover Hinge C-00004284 40-D004250 1
6 Seat Assy Black C-00005847 40-D008680 1
7 Front Panel (Bazel) C-00006042 40-D010962 1
8 Back Cover C-00006043 40-D008950 1
9 Base Assembly C-00006044 40-D008951 1
10
Cables:
Audio Cable, A150X2,18AWG, 180cm CB-00000544 32F2818004 1
11 DVI Cable, S/L, 1.8M, W/2F CB-00002083 32F0000004 1
12 Accessory Cable, D-Sub CB-00004287 32F3018003 1
13 Flat Cable (FFC L=108.5) CB-00004288 32-D004533 1
14 Flat Cable (FFCX816,36) CB-00005742 32-D005773 2
15
Documentation:
Safety Label, 120 mmx50 mm DC-00006045 77-D010603 1
16 Carton Label 76.2 mmx76.2 mm DC-00008035 77-D011986 1
17 CD-ROM (Menu) DC-00008036 76-D011994 1
18
Hardware:
SCREW,3,P=0.5 mm,L=4 mm HW-00000553 42A9930008 16
19 SCREW,3,P=0.5 mm,L=4 mm HW-00000553 42A9930008 4
20 SCREW,M3,P=1.27 mm,L=12 mm HW-00000556 42A9990005 2
21 SCREW,M4,P=0.7 mm,L=8 mm HW-00004042 42-D000649 1
22 SCREW,M4,P=0.7 mm,L=15 mm HW-00005884 42-D001756 4
23 SCREW,4,P=0 mm,L=11.8 mm HW-00006041 42A9940007 4
24
Miscellaneous:
Tape, 900 mmx50 mmx0 mm M-00000560 7345511002 0.058
25
PE Bag
P-00000595
7841919921 1
26 Foam(Right) P-00006049 78-D009100 1
27 Foam(Left) P-00006050 78-D009098 1
28 Generic Foam Set P-00001347 30833
29 Generic Box P-00002515 20653
30 Craft Box P-00008028 78-D011984 1
31
Plastics:
Panel Cover (Panel Protector Film) PL-00006048 73-D005900 1
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
RECOMMENDED SPARE PARTS LIST (VE1920wmb-2)
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by
ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
PC Board Assembly:
Packing Material:
Description
