ViewSonic VG2030m-1 - Recommended Spare Parts List

ViewSonic Corporation Confidential - Do Not Copy
65
7. Recommended Spare Parts List
Serial No. Prefix: QGZ Rev: 1a
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1
Accessories:
Power Cord, VCTF 3G 0.75mm^2 A-00004047
32-D001922
2 Power Switch Board, A201P1-P01-H,A201P1-P01-H-K1,1101-01,Rev.01 B-00005703
35-D007988
3 On Screen Display Board ,A201P1-P01-H,A201P1-P01-H-K2,1101-01,Rev.01 B-00005704
35-D007990
4 Lips With Audio,DAC-12M033 AF,02 A,12 V/0.7 A,5 V/3 A,4L,5 mA,2650 V B-00006040
27-D004260
5 Audio Control Rev.04 B-00008011
35-D008184
6 Back Cover ( Rear Assy, A201P1-H14,Black) C-00005671
40-D007468
7 Cover Hinge - ABS PA-757 C-00008139
40-D013575
8 Front Panel - Silver(TY4818A)/Black(M1077) C-00008140
40-D013516
9 Base Assembly - (Stand Seat) C-00008141
40-D013661
10 Accessory Cable,Audio,NONE,Black,Pins-Pins CB-00000547
32F2818004
11 DVI Cable, S/L, 1.8M, W/2F CB-00002083
32F0000004
12 Accessory Cable, D-Sub CB-00004287
32F3018003
13 Flat Cable (FFC,862P051787A/CFC2108,6 Pins) CB-00005675
32-D007466
14 Flat Cable (FFC,862P051786A/CFC2109,15 Pins) CB-00005676
32-D007464
15 Flat Cable (FFC,0.5x36x117xD(3.5/3.5/5/5),36 Pins) CB-00005677
32-D008152
16 Safety Label - 160 mmx30 mm DC-00008134
77-D013594
17 Carton Label - 76.2 mmx76.2 mm DC-00008135
77-D013595
18 CD-ROM DC-00008136
76-D013600
19 SCREW,3,P=0.5 mm,L=4 mm,Pan Head,Phillips Cross Recess HW-00000553
42A9930008
20 Screw,M3*P0.5*6,Steel HW-00000555
42A9930014
21 Screw,¿3*P1.27*8,¿5.5*2,Steel HW-00000557
42A9930017
22 Screw, M4, P=0.7 mm, L=8 mm Round Head HW-00004042
42-D000649
23 SCREW,4,P=0 mm,L=11.8 mm,Hexagon Stand Off,Socket HW-00006041
42A9940007
24
Miscellaneous:
Tape Security, OPP,L900xW50x0.045mm M-00000560
7345511002
25 PE Bag P-00000595
7841919921
26 Foam - (Bottom) P-00008136
78-D013577
27 Foam (Top) P-00008137
78-D013578
28 Craft Box P-00008138
78-D013593
29 Generic Foam Set P-00001347
30833
30 Generic Box P-00002515
20653
31
Plastics:
Panel Cover - Panel Protector Film PL-00008032
73-D007951
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
Packing Material:
ViewSonic Model Number: VS11234
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation. This is to
eliminate repeated cross checks of each item between this version and prior versions.
Cables:
Documentation:
Hardware:
RECOMMENDED SPARE PARTS LIST (VG2030m-1)
Description
PC Board Assembly:
Cabinets:
VG2030m-1
