Table : 15 pin D-sub connector pin assignment
Pin Number Pin Function
1 Red video input
2 Green video input
3 Blue video input
4 No Connection
5 Ground
6 Red video ground
7 Green video ground
8 Blue video ground
9 +5V
10 Ground
11 No connection
12 (SDA)
13 Horizontal sync (Composite sync)
14 Vertical sync
15 (SCL)
Timing Table
Item
Timing Analog
Digital Remark
1 640 x 350 @
70
Hz,
31.5
KHz
Yes Yes DMT
2 640 x 400 @
60
Hz,
31.5
KHz
Yes Yes DMT
3 640 x 400 @
70
Hz,
31.5
KHz
Yes Yes DMT
4 640 x 480 @
50
Hz,
24.7
KHz
Yes Yes DMT
5 640 x 480 @
60
Hz,
31.5
KHz
Yes Yes DMT
6 640 x 480 @
67
Hz,
35.0
KHz
Yes Yes For MAC
7 640 x 480 @
72
Hz,
37.9
KHz
Yes Yes DMT
8 640 x 480 @
75
Hz,
37.5
KHz
Yes Yes DMT
9 640 x 480 @
85
Hz,
43.3
KHz
Yes Yes DMT
10
640 x 870 @
75
Hz,
68.9
KHz
Yes Yes MAC
11
720 x 400 @
70
Hz,
31.5
KHz
Yes Yes DMT
12
720 x 400 @
85
Hz,
37.9
KHz
Yes Yes DMT
13
720 x 480 @
60
Hz,
31.5
KHz
Yes Yes 480p
14
720 x 576 @
50
Hz,
31.3
KHz
Yes Yes 576p
15
800 x 600 @
50
Hz,
24.7
KHz
Yes Yes DMT
16
800 x 600 @
56
Hz,
35.1
KHz
Yes Yes DMT
17
800 x 600 @
60
Hz,
37.9
KHz
Yes Yes DMT
18
800 x 600 @
72
Hz,
48.1
KHz
Yes Yes DMT
19
800 x 600 @
75
Hz,
46.9
KHz
Yes Yes DMT
20
800 x 600 @
85
Hz,
53.7
KHz
Yes Yes DMT
21
832 x 624 @
75
Hz,
49.7
KHz
Yes Yes MAC
22
1024 x 768
@
50
Hz,
39.6
KHz
Yes Yes DMT
23
1024 x 768
@
60
Hz,
48.4
KHz
Yes Yes DMT
24
1024 x 768
@
70
Hz,
56.5
KHz
Yes Yes DMT
25
1024 x 768
@
72
Hz,
58.1
KHz
Yes Yes DMT
6
