ViewSonic Corporation Confidential - Do Not Copy VA1930wm-1
8
6 FRONT PANEL CONTROLS AND INDICATORS
Front Panel Hardware Controls
Power Switch (Front Head) Power Control, soft Power Switch.
Power LED (Front Head)
Green – ON
Orange – Active Off
Dark = Soft Power Switch OFF
Front Panel Controls (Head)
[
] [ 1 ] [ 2 ] [▲] [▼]
[;X] Mute
[
] Power
[ 1 ] Button 1
[ 2 ] Button 2
[▲] Up arrow button
[▼] Down arrow button
Note: Power Button, Button 1 and Button 2 must be
one-shot logic operation. (i.e. there should be no
cycling)
Reaction Time
OSD must fully appear within 0.5s after pushing Button
1
Short Cuts Function from the button(s)
[1] Main Menu
[2] Input toggle (Analog or Digital; refer to Appendix D)
[▼] Brightness adjust
[▲] Contrast adjust
[▼]+ [▲] recall both of Contrast and Brightness to default
[1] + [2] toggle 720x400 and 640x400 mode when input 720x400 or 640x400
mode
[1] + [▼] + [▲] White Balance. (Not shown on user’s guide)
[1] + [▼] Power Lock
[1] + [▲] OSD Lock
[1] + [▼] + [2] Disable Theft Defence function
[▲]+ [ ] + Main Power On All reset
No signal + [ ] + [2]
+ Main Power on
Burning mode
Signal + [2] + [ ] + Main Power
On
Factory Mode
Remark : All the short cuts function are only available while OSD off
