ViewSonic Model Number: VS11354
Rev: 1a
Serial No. Prefix: QFP
Item ViewSonic P/N Ref. P/N Description Q'ty
1 C-00008181 714030007410R ASSY,BEZEL,NO silkscreen,LE1945 1
1-1 N/A 501010207710R BEZEL, Front,NO silkscreen,LE1945 1
1-2 N/A 501030204300R Button,Power key,LE1941 1
1-3 N/A 501120104400R LENS, LE1941 1
2 N/A 501060200500R holder,Keypad,LE1941 1
3 N/A 501030204400R button,function key,LE1941 1
4 N/A 509112306100R SCREW,P,CROSS T.T-3*6,Zn,ROHS 3
5 N/A 714088061100R ASSY,Panel,W/SPK LE1945 1
5-1 E-00008016 631102090600R Panel INNOLUX 1
5-2 E-00008012 618100101500R Speaker 1.5W 1
5-3 N/A 509146304100R SCREW,P,CROSS W/WAS,M3*4,Zn ROHS 4
5-4 B-00008024 790691501000R PCBA,KEY PAD BOARD,LE1941 1
5-5 B-00008023 790691401600R PCBA,P/I Board,LE1941 1
5-6 N/A 502090304100R CHASSIS,W/DVI, LE1941 1
5-7 B-00008165 790691302600R PCBA,I/F Board,LE1945 1
5-8 HW-00005269 509146305300R SCREW,PW,CROSS,W/WAS,M3*5,NI 6
6 N/A 501020209400R COVER,BACK(B),W/DVI, LE1941 1
7 N/A 503040000310R Rubber,COVER(B) 1
8 N/A 509142306500R SCREW,P,CROSS W/WAS,T.T3*6,BLK ROHS 2
9 PL-00008045 714010008600R ASSY,STAND LE1945 1
10 N/A 509116608100R SCREW,P,CROSS,M4*8,Zn,ROHS 4
11 C-00008182 501020209600R Cover,hinge,LE1945 1
12 B-00008025 790682201000R PCBA,LED BOARD, LE1941 1
EXPLODED PARTS LIST (VA1930wm-1)
ViewSonic Corporation Confidential - Do Not Copy VA1930wm-1
50
