ViewSonic VX910 User Manual

ViewSonic VX910 6
Wall Mounting (Optional)
To obtain a wall-mounting kit, contact ViewSonic
®
or your local dealer. Refer to the
instructions that come with the base mounting kit. To convert your LCD display from a desk-
mounted to a wall-mounted display, do the following:
1. Verify that the Power button is turned OFF, then disconnect the power cord.
2. Lay the LCD display face down on a towel or blanket.
3. Remove the rear panel covers from the back of the LCD display.
4. Remove the four screws attaching the base.
5. Remove the Rubber Plugs from inside the four VESA screw holes.
6. Attach the mounting bracket from the VESA compatible wall mounting kit (100 mm x 100
mm distance).
7. Attach the LCD display to the wall, following the instructions in the wall-mounting kit.
Four VESA
screw holes
Four base screws
Rear panel
covers

ViewSonic VX910 Specifications

General

Pixel pitch	0.294 mm
Response time	16 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	50 - 85 Hz
Horizontal scan range	24 - 82 kHz
Viewable size, vertical	301 mm
Viewable size, horizontal	376 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	250 cd/m²
Certification	TCO’99, TÜV/GS, TÜV/ERGO, ISO13406-2 (class 2), CE, UL, cUL, FCC-B, CB, ENERGY, NOM, NEMKO, NEMKO ERGO, GOST-R, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, Argentina-S, Green Mark
Market positioning	-
Power management	TCO’99, ENERGY Standards
Tilt angle range	5 - 20 °
Compatibility	PC/Mac
Operating relative humidity (H-H)	10 - 90 %
Maximum operating temperature range (T-T)	0 - 40 °C

Weight and Dimensions

Depth (without stand)	468 mm
Width (without stand)	431 mm
Height (without stand)	201 mm
Weight (without stand)	6700 g
