Gasifying boiler VIGAS
13.1.3 Exhaust gas thermometer settings
13.1.4 Discharge fan settings
13.1.4 Maximum chimney temperature settings
13.1.5 Frequency power supply set up
13.1.6 Temperature unit setting
13.1.7 Summer time setting
13.2 MODUL AK 4000M SETTINGS
19
In necessary cases it is possible to connect AK4000 control to modul AK4000M (pic.8). This modul
allows to provide upgrades and back-up data maintenance of the boiler control unit. Modul is equipped
with data - in line with possibility to connect to BH BUS power board.
In case of exhaust gas thermometer error it is possible
to disconnect thermometer from operation. It is possible
to operate boiler untill replaced as a standard model.
Exhaust gas thermometer will not be used. To
deactivated boiler use boiler thermometer, yes – boiler
with thermometer, no – boiler without thermometer.
Discharge fan is an accessory that can be used with
boiler. After connecting to the boiler and into the control
AK4000, it is necessary to choose option „yes“.
yes – boiler with discharge fan, no – boiler without
discharge fan.
MaxT
Maximum chimney temperature setting can be
selected between 75 °C up to 90 °C. Highest value is
used for boiler setting with accumulator tank.
Frequency power supply setting. It is 50 Hz for EU
residents and 60 Hz for USA and Canada residents. If
you are not aware of power supply frequency choose
AUTO. Incorrect frequency can cause clock error.
Temper.
unit
Temperature unit set up. Allows to select °C or F -
Fahrenheit.
Summer
Allows to set up automatic change of clock to summer
time.
